Preserving pot / Milk cooling tank/ Cooling machine
Preserving pot / Milk cooling tank/ Cooling machine structure
1) Tank: tanks liner, mezzanine and outside wrapping is made from 304 stainless steel plate, the argon arc welding, precision polishing, dirt not easily stored up. In between, the shell of tank filled with polyurethane foam insulation materials, inner tank of the lateral configuration has the corresponding area of direct evaporation cooling jacket plate.
2) Agitator: composed of motor, reducer and mixing device. Mixer and tanks use flange connection, by the worm gear speed reducer drive agitator.
3) Cooling system: cooling system by the refrigeration unit clamp, cold plate, etc. Honeycomb jacket is applied in the cooled jacketed straight effect is ideal; Refrigeration unit according to the need refrigeration unit configuration corresponding water cooled condenser (with the use of high environmental temperature, need not when row as cooling water) compressor chooses the superiorly happy valley or round, reliable operation, energy saving, durable, refrigeration effect is ideal.
Preserving pot / Milk cooling tank/ Cooling machine technical parameters
Style No |
Capacity(L) |
Cooling capacity(W) |
Cooling medium |
Thermal insulation properties |
Stirring speed |
Matched power |
Power supply |
DH-05A |
500 |
3604 |
R22 |
24h≤2.0°C |
37r/min |
3KW |
380V-50HZ |
DH-08A |
800 |
5292 |
R22 |
24h≤2.0°C |
37r/min |
4.0KW |
380V-50HZ |
DH-1A |
1000 |
6678 |
R22 |
24h≤2.0°C |
37r/min |
5.0KW |
380V-50HZ |
DH-1B |
1000 |
6678 |
R22 |
24h≤2.0°C |
37r/min |
5.0KW |
380V-50HZ |
DH-1.5B |
1500 |
11340 |
R22 |
24h≤2.0°C |
37r/min |
5.5KW |
380V-50HZ |
DH-2B |
2000 |
14288 |
R22 |
24h≤2.0°C |
37r/min |
6KW |
380V-50HZ |
DH-5C |
5000 |
14288*2 |
R22 |
24h≤2.0°C |
37r/min |
6*2KW |
380V-50HZ |
