Vertical colloid mill (JML-100)
JML-100 vertical colloid mill is making of stainless steel, half of stainless steel. Vertical means that there is vertical motor with gear grinding, the motor is installed vertically.
Vertical colloid mill (JML-100) usage
Colloid mill is mainly used in the food industry, chemical industry, pharmaceutical industry, daily industry, building industry, papermaking industry, plastic industry, battery industry, etc. Its structure is made by grinding the head piece, the base drive; Special motor of three parts.
Vertical colloid mill (JML-100) characteristics
Relative to the pressure-type homogenizer, colloid mill first is a kind of centrifugal equipment.
It has the advantage of simple structure, equipment maintenance convenient, suitable for high viscosity materials and large particles of the material.
Its main drawback is decided by its structure. First of all, due to eccentric exercise, the traffic is not a constant; the corresponding to the same sticky material flow has changed a lot.
The same equipment, for example, in dealing with the paint sticky materials and thin milk fluid, the traffic can be a difference of more than 10 times; Second, due to the friction between the stator and the material, so easy to produce a larger quantity of heat, make the treated material degeneration; Third, the surface is easy to wear and abrasion, refine the effect will be dropped significantly.
Vertical colloid mill (JML-100) technical parameters
Style No. |
JML-100 |
|
Emulsification fineness um (single or multiple loop) |
2~40 |
|
Adjusting range mm |
1-0.01 |
|
Production t/h According to the material properties |
0.5-2 |
|
|
Motor |
Power KW |
5.5 |
Voltage V |
380 |
|
Speed rpm |
2880 |
|
Burrs diameter mm |
DN 100 |
|
Discharging mouth diameter (time) |
DN 32 |
|
Cooling water pipe diameter(time) |
DN 1/4 |
|
Overall size |
Length mm |
560 |
Wide mm |
420 |
|
Height mm |
950 |
|
Weight kg |
113 |
|
