Specifications
Wheat and Corn combine harvester+ 3 rows corn header / 2360mm wheat cutter blade
+ 90 HP engine
+ harvest corn and wheat
Wheat and Corn combine harvester
4YZ-3 wheel self-propelled header interchangable Corn&Wheat Combine Harvester
harvester corn plant status ( with corn cutter header)
Harvester wheat crop status (change into wheat cutter bar)
One host machine with two sets harvesting mechanism, one for corn,another for wheat, you can harvester this two crops through change cutter header and some parts.
Favorable Performance :
1. Use of Interchangeable header can fulfill many functions and increase working hours. ( can harvester wheat & corn ).
2. Self-propelled type, reasonable structure obtains convenient operation.
3. Lower loss rate, more function and lower price.
4. Stable performance and good suitability.
5. Can harvest wheat through change the wheat header and some parts
Technical parameter :
Specification sheet for 4YZ-3 corn & wheat combine harvester
Model |
4YZ-3 Header Interchangeable Combine Harvester |
Size (Central Distance) |
700 Left /670 Right |
Matched Motor |
66KW (4LZ-2.6) |
Productivity (Hectare/h) |
0.27-0.53 |
Oil consumption |
≤ 30Kg/Hec |
working Speed |
1.5-3.5 Km/h |
Running speed |
1.78-20 Km/h |
Whole Quantity |
6400kg |
Number of Working Lines |
3 |
Perfect Row Spacing |
600-700mm |
Suitable Row Spacing |
550-850mm |
Lowest Height of Ears |
≥500mm |
Dimension (Length×Width×Height) |
7860×2000×3600(mm) |
Minimum Turn Radius |
5.2m |
Cutter Type |
Claw Type and Throw Falchion Type |
Number of Claws |
12 |
Rotate Speed of Cutter Spindle |
1860 rev/s |
Working Width of Back-to-the-field Machine |
1800mm |
Spread Width of Back-to-the-field Machine |
1800-2000mm |
Clearance apart from Land |
≥300mm |
Minimum Stubble Height |
≤50mm |
Grain Tank Capability |
2.5 Stere |
Unloading Type |
Hydraulic unloading |
Qty’/40HC |
1 set |
