Kobelco Excavator Specifications JGM924 Crawler Excavator Machines Used

Kobelco Excavator Specifications JGM924 Crawler Excavator Machines Used photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
jingong
Model Number:
JGM924
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name jingong
Model Number JGM924
Condition New
Moving Type Crawler Excavator
Operating Weight 24000KG
Bucket capacity 1.12m³, 1.12cbm
Maximum Digging Height 9600mm
Maximum Digging Depth 6700mm
Machine Weight 24000KG
Max Digging Radius 10000mm
Rated Speed 5.5km/h
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

kobelco excavator specifications JGM924 crawler excavator machines used



kobelco excavator specifications JGM924 crawler excavator machines used





Product Description





Name

Unit

Technical specifications

Operating weight

Kg

24000

Bucket capacity

m3

1.2

Overall length

A

mm

9678

Total width

B

mm

2990

Total hight

C

mm

3088

Width of the turntable

D

mm

2840

Ground clearance of counter weight

F

mm

1080

Height of counter weight top

G

mm

2070

Min.ground clearance

H

mm

468

Turntable tail length

I

mm

3075

wheel case of track

J

mm

3640

The length of the chassis

K

mm

4443

Gauge of track

M

mm

2390

Standard track width

N

mm

600

Travel speed

Km/hr

3.4/6.2

Swing speed

rpm

11.8

Ground pressure

KPa

44 (600mm Track plate)







Standard equipment:



l Engine (Original import ISUZU ENGINE  )
l Hydraulic oil, oil (Shell or Mboil)
l Main hydraulic pump (Original import Japan Kawasaki brand)
l High energy maintenance-free battery (-12×12V20hA)
l Main valve (Original import Japan Kawasaki brand)
l Starter motor (24V-5kW)
l Pilot control valve (Original import Japan Kawasaki brand)
l Anti-swing during slewing
l Slewing motor (Original import Japan Kawasaki brand)
l Slewing priority
l Travel motor (Original import Japan Kawasaki brand)
l Travel straight retaining
l Hydraulic oil cylinder (Original import Japan Kayaba )
l Dual-speed shift automatically during



l Hydraulic accessories (Manuli, Parker)
l Heavy duty slewing support (sealed lubrication)
l Track shoekobelco excavator specifications JGM924 crawler excavator machines usedkobelco excavator specifications JGM924 crawler excavator machines used



kobelco excavator specifications JGM924 crawler excavator machines usedkobelco excavator specifications JGM924 crawler excavator machines used



kobelco excavator specifications JGM924 crawler excavator machines used
