ZL16F Mini Wheel Loader

Name: ZL16F Mini Wheel Loader
Brand: Jingong
SKU: 141344740
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

Jingong

Model Number:

ZL16F

Fujian Jingong Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Jingong

Model Number ZL16F

Place of Origin Fujian, China

Type Mini Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 5182*1910*2712mm

Rated Load 1600kg

Certification ISO

Performance	1	rated loading	1600kg
	2	overall weight	4870kg
	3	rated bucket capacity	0.9m³
	4	maximum tractive force	≥34KN
	5	maximum breakout force	≥51KN
	6	maximum grade ability	30°C
	7	maximum dump height	2330mm
	8	maximum dump reach	800mm
	9	overall dimension (L×W×H)	5182×1910×2712mm
	10	minimum turning radius	4367mm
Engine	11	model	Wei chai ZH4100K14-3
	12	type	Vertical, in-line, water cooled, 4-stroke diesel engine
	13	No. of cylinder-bore/stroke	4—100×125mm
	14	rated power	45kw—2400r/min
	15	maximum torque	250N.m
	16	min fuel-consume ratio	≤243g/kw.h
Transmission system	17	torque converter	YJ1—26501
	18	gearbox mode	Countershaft power-shift
	19	gear shift	2 forward shift 2 reverse shift
	20	maximum speed	24km/h
Drive axles	21	main reducing spiral	Circular Arc Bevel gear, single stage
	22	decelerating mode	Single stage planetary type
	23	wheelbase (mm)	2150mm
	24	wheel tread	1440mm
	25	ground clearance	310mm
Hydraulic system	26	system working pressure	16MPa
	27	boom lifting time	4.8s±0.2s
	28	total time	9.2s±0.5s
	29	fuel tank capacity	80L
	30	function of leveling automatically	yes
Brake system	31	service brake	air assist disc brake on 4 wheels
Brake system	32	parking brake	flexible shaft operated external drum
Tyre	33	type specification	16/70—20
	34	front tyre pressure	0.22Mpa
	35	rear tyre pressure	0.18Mpa
