Help CenterAutomatic Control Wood Pellet Fired Steam Boilerhot Hot Sale Industrial Energy-saving Boiler
Related Products
-
New Best Biomass Air Heater Furnace Wood Pellet Boiler Professional Stove With CE CertificateUS$ 3,000 - 15,000MOQ: 10 Sets -
Wood Pellet Hot Water Industrial Boiler China Best Sale High Efficiency Automatic Pellet BoilerUS$ 1,800 - 40,000MOQ: 10 Sets
-
Wood Burning Stoves Ovens Smokeless Wood Burning Stove 12KW Insert FireplaceUS$ 100 - 800MOQ: 100 Sets
-
Wood Burning Stoves Ovens High Quality Wood Stoves China 14KW Cheap Wood FireplaceUS$ 100 - 800MOQ: 100 Sets
-
Insert Cast Iron Wood Stove Door Big Burner Stove Chinese Cheap and High Quality 2016US$ 200 - 1,000MOQ: 100 Sets
Zhejiang Zhongli Tools Manufacture Co., Ltd. was established in 2005, located in the cabled Hardware Technology Industrial Park in Jinyun county in Zhejiang province, is a integrated modern high-tech enterprise with collection of research and development, production and sales . It specializes on the development of garden tools, agricultural machinery, bio heat energy equipment and other products. The annual production is more than 1,000,000 sets of all kinds of garden tools and more than 100,000 sets of bio energy equipment.
The products are exported to Americas, Europe, Australia and Southeast Asia more than 30 countries and regions, which won the customers’ widely recognized. The performance index of the products is leading in the domestic, reached the advanced world level. ISO9001:2008 quality system standard was fully implemented. The products through the GS, CE, EMC, VCA, ROHS, EPA and EURO II certifications, at the same time, enterprise obtained the national high-tech enterprise and a well-known trademark in China title, and selected “national agricultural machinery supporting the promotion directory”.
The company adheres to the concept of "loyal to innovation, strive for perfection", committing to innovation, and multi-channel to promote the R & D and innovation ability of product and technology. We are sticking to the development strategy of“high starting point, high-tech, high-quality, low energy consumption, low emission and low consumption”, gathering all kinds of elite talent and constructing the perfect independent innovation system. The leading technology in the tool industry; low carbon economy in bio heat energy field, the construction of ecological civilization, and promoting the harmonious development of man and nature, this is the lofty goal of Zhejiang Zhongli always persisting in. Furthermore, we established long-term cooperation with a number of research institutions and universities. In the aspect of products, the company makes introduction, digestion, absorption and independent innovation, and gradually forms its own technological advantage.
Now, the Zhongli people are bearing the new hope and driving the n ew opportunities, and with high quality and efficient services to create new brilliance with home and abroad customers!
| Exhaust Blower Power(KW) | 0.75 | Convection Blower Power(KW) | 0.25 |
| Ignitor Power(KW) | 1.2 | Auger Motor Power(KW) | 0.2 |
| Pump Power(KW) | 2.2 | Pump Lift(M) | 120 |
| Flue Temperature(℃) | ≤150 | Standrad Water Volume(L) | 28.5 |
| Total Heating Surface | 3.2 | Flue Pipe Diameter(MM) | 133 |
| Water Inlet Pipe M2 | DN15 | Steam Outlet | DN20 |
| Combustion Means | Suspended and Flow (Negative Pressure in Chamber) |
Control Means | Infrastructure Integration,firepower automatically changed according to water temp. |
| Security Performance | Low Water Level Cut-off Device,Over Pressure Protection |
Operation Means | One Button Start |
| Boiler Weight(KG) | 315 | Gross Weight(KG) | 450 |
| Dimension(MM) | 1650*600*1600 | Hopper Dimension | 600*500*650 |
| Fuel Efficiency(kg/h) | 16-18 | Heat Efficiency | ≥85% |
| Grate AreaM2 | 0.05 | Rated Pressure of Steam(Mpa) | 0.7 |
| Rated Temp. of Steam(℃) | 170 | Rated Evaporation Volume(kg/h) | 100 |
