River Sand Pump Dredger for Namibia sand dredging quipment

Sand mining machine , dismoutable suction dreger machinery

Suction dredger is currently the sand dredging projects, collecting sand industry in using the most flexible convenient work ship.It is the use of pump suction principles through straws ends water cannons spewing out water cannons to bottom sediment impact and the formation of certain concentration mixture,Then by centrifugal pump of blending materials to be delivered through the row tube to accumulation point.The boat equipment, complete floating bodies deft, facilitate transportation, is a kind of high efficiency, low cost of sand mining ship. Is a good sand equipment, for first-time investors trial and investment.

Dismountable sand suction dredger consists of three pontoons: one main pontoon and two side pontoons. The pontoons are connected by the connecting pieces and tightened by high intensity bolts and nuts.

This ship all equipment design for diesel engine drive .

Application: sand suction and dredging projects at near shore, in lakes, reservoir and harbor.

Specification :

1.  Hull :

The hull uses dismantle and box-like structure, which equipped with horizontal shifting devices, cutter ladder lifting devices, spud devices, deck crane and so on. It can also be equipped with anchoring poles and trolley devices. Generally, it has functions on dredging, conveying and discharging of mud or sand. It can produce certain amount of vacuum by the centrifugal pump.

Single Hull Size: 18m×1.52m×1.5m (L.W.H)        DOUBLE HULL

Engine Room: 12m×2.82m×2.3 m                 ONE

Material : Ship bound for 6mm

                 Bottom plate. For 8mm

                 Deck 5mm board

Anti-corrosion treatment for the bottom

Two layers of anti-rust primer

Epoxy-polyurethane coating on the surface

Maximum dig deep: 15m

2. Dredger Pump :

Model:12 Dutch type mixing mud pump           Origin:GUANGDONG

Total flow:1500m³/h~2000m3/h                         Lift head:50m

Capacity range: 150m3/h~200m3/h

 Horizontal dischange distance : 300 m

3. Diesel Engine

Product name: NT129L                                      Brand:Nantong Power

Rated speed: 1500 r/min
Number of cylinders: 6

Dimension: 1435 mm × 797 mm × 1236 mm

4. Auxiliary Engine

Auxiliary engine provide 24V DC electricity

Inspiratory way:inter-cooled turbocharged

Applicability this machine: To pass low bridge easily, the controlling room and rest room are dismountable. Connecting parts for cabin room and deck are easily dismounted joints.

Working site of cutter suction dredger: sea, port, lake, and river.

Soil conditions:  river sand, clay, mud, and so on.

The design, construction, quality inspection is according to the standards and regulations of CCS. The hull, machinery equipments and other spares are at the requirements of CCS.  The hull is square, cross keel, which is full welding steel structure.

Quality Warranty :

     Every cutter suction dredger is built by skilled workers and inspected strictly to assure the high quality and durability. Each finished dredger will be tested in our testing center to make sure it works smoothly when delivering to customers.

Will provide 12-months warranty for the quality of the main parts: Diesel engines, generators, gear boxes, dredge pumps, Hydraulic system.

1) 12 months manufacturing warranty on all new installed component parts.

2) 12 months warranty on hull and all fabricated parts.

3) Wearing parts are not included.

During the warranty period , We will provide free parts and on-site technical guidance . After the warranty period, We will provide free and on-site technical support quickly, if the ship-owner need. But if the dredger need replacement parts, the cost paid by the owner.

Delivery :

     The cutter suction dredgers are detachable, so it is easy to transport when delivering or moving from one working site to another.

Training and installation :

Our experienced installers will arrive at the construction site to guide, teach and training your staff to debug and operate the dredger until they can operate skillfully by themselves.
