Abrasive and corrosive resistant dredger pump for dredger diesel engine driven
- 8 Set / Sets per Month
- Qing Dao
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
- 2018 Hot newest small 1000m3 Sand Cutter Suction Boat
- Customized small 12 Inch cutter suction river dredging equipment
- 2022 Hot Newest Small 1200m3 Cutter Suction Dredger Manufacturer Sand Pump Suction Dredger Sand Dredging High Gold Recovery Rate
Product Details
Condition: | New | Type: | Other, Slurry pump, Slurry pump | Power Type: | Diesel |
Place of Origin: | Shandong, China | Brand Name: | Yuanhua | Model Number: | YHP |
Weight: | 2.5t | Certification: | ISO 9001:2008 Certification | Warranty: | 1 year |
Product Description
Abrasive and corrosive resistant dredger pump for dredger diesel engine driven
Widely application: They are designed for handling abrasive, high density slurries in the metallurgical, mining .
Available to use multiple series, to satisfy the long-distance transmission requirements
High efficiency hard alloy, and low NPSH
To meet the different operation conditions, adopted the brief type structure bearing parts, selected high bearing capacity design, alloy bearing grease lubrication oil.
Through adjusting the clearance between protection board and impeller, ensuring the pump efficient operation,
Using packing seal, impeller sealing , container type mechanical seal to adapt to different operating mode requirement.
Our sand dredging machine are designed by senior engineer, who have specialized in shipbuilding and dredging work for many years, to guarantee they are well-designed and practical.
| MODEL | FLOW m3/h | HEAD m | MOTOR POWER kw | SPEED | EFFCIENCY | MAX PARTICLE | OUTPUT DIAMETER mm |
|
1 | YHQ30-30-7.5 | 24 | 31 | 7.5 | 1460 | 43 | 13 | 80 | √ |
30 | 30 | ||||||||
36 | 29 | ||||||||
2 | YHQ50-21-11 | 35 | 22 | 11 | 1460 | 48 | 21 | 100 |
|
50 | 21 | ||||||||
60 | 20 | ||||||||
3 | YHQ100-16-11 | 70 | 20 | 11 | 1460 | 55 | 21 | 100 | √ |
100 | 16 | ||||||||
120 | 15 | ||||||||
4 | YHQ50-26-15 | 35 | 29 | 15 | 1460 | 48 | 13 | 100 | √ |
50 | 26 | ||||||||
60 | 24 | ||||||||
5 | YHQ60-30-15 | 42 | 33 | 15 | 1460 | 50 | 13 | 100 | √ |
60 | 30 | ||||||||
72 | 27 | ||||||||
6 | YHQ100-18-15 | 70 | 20 | 15 | 1460 | 55 | 21 | 100 | √ |
100 | 18 | ||||||||
120 | 15 | ||||||||
7 | YHQ150-15-15 | 105 | 17 | 15 | 1460 | 56 | 21 | 150 | √ |
150 | 15 | ||||||||
180 | 13 |
