Help CenterHot Selling Large Output Iron Sand Ore Dredging Equipment Mining Machine
Related Products
-
River Sand Iron Sieving Equipments High Capacity Dredger, Low Price DredgerUS$ 45,000 - 78,000MOQ: 1 Set -
River Sand Iron Sieving Equipments High Capacity DredgerUS$ 45,000 - 78,000MOQ: 1 Set
-
Iron Dredges Equipments High Capacity DredgerUS$ 45,000 - 78,000MOQ: 1 Set
-
Iron Sand Ore Screening Dredger Ship Land UseUS$ 45,000 - 78,000MOQ: 1 Set
-
Iron Sand Machinery Iron Ore Extracting Dredger Ship Land UseUS$ 42,000 - 78,000MOQ: 1 Set
Iron sand ore dredging equipment with ISO 9001:2008 Certification
Heavy machinery is used in mining for exploration and development, to remove and stockpile overburden, to break and remove rocks of various hardness and toughness, to process the ore and for reclamation efforts after the mine is closed. Bulldozers, drills, explosives and trucks are all necessary for excavating the land. In the case of placer mining, unconsolidated gravel, or alluvium, is fed into machinery consisting of a hopper and a shaking screen ortrommel which frees the desired minerals from the waste gravel. The minerals are then concentrated using sluices or jigs.
Hull | |
Dimension (l*w*h) | 13.5m×1.5m×0.9m side floating bodies/double |
Engine Room (l*w*h) | 2m×1.5m×1m middle floating body |
Other | Anti-rust primer painted at the bottom Anti-rust coating painted at the surface |
Body | 4mm steel plate |
Deck | 3mm anti skid plate |
Engine Room | 5mm steel plate |
Total Width | 4.5~ 5 m |
Height of holding frame | 4.2~ 5.5 m |
Sand Pump Unit | |
Model | 8 inch |
Suction dia. | 200 mm |
Discharge dia. | 200 mm |
Capacity | 80 m³/h (consistency 20%) |
Fitted Power | 59 kw |
Speed | 700 rpm |
Suction Depth | 15 m |
Driving Engine | HFR4105IZG WEIFANG·HUAYUAN |
Speed | 2000 rpm |
Power | 74 kw |
Oil consumption | ≤197g/kw.h |
Water Pumping Unit | |
Capacity | 100 m3/h |
Head | 15 m |
Fitted Power | 20HP diesel engine |
Magnetic Separation Equipment (permanent magnet roller type) one set | |
Size | 3000*900mm (water-washing precise selection type) |
Antimagnetic angle | 120° |
Selection Mode | downstream type/forward flow |
Super Antimagnetic | Top Magnetic Force: 4300GS |
Recovery Rate | 90% net selection |
Fitted Power | 7.5kw standard motor Model 350 reducer |
Iron Sand Grade | 50-55 depend on original ore magnetic holding rate |
Submersible Pump | 7.5 kw ,one set |
Winch | |
Ladder rising winch | 4kw electric winch , one set |
Hand operating winch | 2 sets |
Simple control room | |
Light | 2 sets |
Power Unit | |
Model | HFR4100ZD WEIFANG·HUAYUAN |
Generating power | 30 kw |
Speed | 1500 rpm |
Rated Current | 72 A |
Rated Voltage | 400 V |
Oil Consumption | ≤197g/kw.h |
Propeller |
|
Impeller diameter | 500 mm |
Length | 1.8m |
Fitted Power | 20HP diesel engine |
Iron Sand Discharging Pump | |
Model | 4 |
Fitted Power | 24HP diesel engine |
Attachments |
|
Main pump 8inch impeller | 3 pcs |
Water pump 4inch impeller | 5 pcs |
Working mode:
pump sand from water
- separate stone through simple sieve
- enter the water tank
- materials flow steady into the magnetic roller through the slide board
- iron extraction
- iron sand being discharged to shore by sand pump which is driven by diesel engine
- wastes being dumped through chute
Feature:
Large output, less investment,
high efficiency, easy operation,
a dual-purpose machine,selecting iron,
wash yellow sand can process at the same time,
selecting high-grade iron.
Qingzhou Yuanhua Machinery Manufacture Co., Ltd. We specialize in dredgers for various industries: Construction, Environmental, Sand Production and Mining Machine.
Produce a variety of series products , such as : cutter suction dredger , bucket chain dredger , underwater pump dredger , self- propelled dredger , gold panning dredger , iron extracting dredger, iron extracting equipments , sand sieving machines, crusher , weathering sand producing lines (break , rinsing and separating ), and various kinds of machines for land and watercourse mining of rare metals.
Own professional R&D department , CAD drawing design center , quality control department and Installation & Adjustment to After Service .
We can customize special dredging and mining equipments according to different environment and customer requirement which can accomplish the whole set of working procedures of filtering , extracting , separating, washing , classifying and put our qualified products directly. Our experienced engineers will work closely with you to customize a best dredging solution for your particular needs.
Established in 1994 , now we have developed a dominant role in the dredge manufacturing industry and expand our market to more Russia , Korea , South Asia , Kazakhstan , South Africa , Middle East etc. Success is based on the best quality , excellent service , good credit, competitive price , the abundant strength
