5kva Silent Diesel Generator 186FA With Low Noise Running
US$ 88 - 288
/ Set
2 Sets(Min. Order)
- shanghai/ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HUICHUANG | |
| Model Number | HC-G6500 | Output Type | DC | |
| Speed | 3000/3600rpm | Frequency | 50/60Hz | |
| Rated Power | 5kva | Rated Voltage | 115/230,120/240 | |
| Rated Current | 12V./8.3A |
Product Description
5kva silent diesel generator 186FA:
| Model | HCD6500E | ||
| Frequency (HZ) | 50 | 60 | |
| Rated Output (KVA) | 4.5 | 5 | |
| Maximum Output (KVA) | 5 | 5.5 | |
| Rated Voltage (V) | 115/230 | 120/240 | |
| Rated current (A) | 39.1/19.6 | 41.7/20.8 | |
| Rated rotation speed (rpm) | 3000 | 3600 | |
| Phase No. | Single phase | ||
| Power Factor | COS=1 | ||
| Excitation Mode | Self-excitation, 2 pole and constant voltage (AVR) | ||
| Panel Type | General Panel | ||
| DC Output | 12V./8.3A ,Connection Pole Output | ||
| Structure Type | Open frame type | ||
| Noise Level (7m) dB(A) | 77 | ||
| Engine Model | HC186FA | ||
| Engine type | Single-Cylinder, Vertical, Four-Stroke, Direct Injection,Air Cooled Diesel | ||
| Bore × Stroke(mm) | 86×72 | ||
| Displacement (L) | 0.418 | ||
| Rated Power KW | 5.7/3000 | 6.3/3600 | |
| Fuel comsumption Rate(g.kw/h) | 275.1 | 281.5 | |
| Compression Ratio | 19:01 | ||
| Lubrication System | Pressure Splashed | ||
| Starting System | Electric Start with 30Ah MF battery | ||
| Fuel Type | 0#(summer),-10#(winter),-35#(chilliness) diesel | ||
| Lube Oil Brand | SAE10W30 (above CD Grade) | ||
| Lube Capacity (L) | 1.65 | ||
| Fuel Tank Capacity (L) | 12.5 | ||
| Continuous Running Time (hr) | 8 | ||
| Overall Dimension: LxWxH (mm) | 750 x 520 x 660 | ||
| Dry Weight (Kg) | 100 | ||
| Quantity in 20FT | 99 Pcs | ||
| Optiomal Features: | |||
| ATS | Optional | ||
| Digital Panel | Optional | ||
| Remote control | Optional | ||
| We reserve the right to change specifications without notice | |||
