Help Center150L High Quality Extractor of Essential Oil on Sale (EC)
Related Products
-
50L Automatic Sunflower Essential Oil Extract Machine on SaleUS$ 10,862 - 11,405MOQ: 1 Set -
30L High Quality Plants Essential Oil Distillation Unit on Sale (EC)US$ 7,000 - 7,350MOQ: 1 Set
-
20L Pure Plants Essential Oil Steam Distillation for Plants on Sale (EC)US$ 6,904 - 7,249MOQ: 1 Set
-
20L Pure Plants Essential Oil Making Machine for Plants on Sale (EC)US$ 6,904 - 7,249MOQ: 1 Set
-
20L Better Pure Essential Oil Extractor for Plants on Sale (EC)US$ 6,904 - 7,249MOQ: 1 Set
Specifications
1. Basket in water.2. Operation part has adopted PLC or touch screen control system, this accords to customer's demand.
| Model | EC10 | EC20 | EC30 | EC50 | EC100 | EC150 | EC200 | EC300 |
| Voltage | 10V | 20V | 30V | 50V | 100V | 150V | 200V | 300V |
| Power | 4.0KW | 4.5KW | 5.5KW | 9KW | 12KW | 14KW | 25KW | 25KW |
| Specifications |
1. Steam extraction part is popular with the structure of basket-in-water 3. This unit is automatically operate. 4. All kinds of plants can be the material of Extractor of Essential Oils. |
|||||||
1. Brief instruction of Extractor of Essential Oils
Extractor of Essential Oils is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.
2. Special Design of Extractor of Essential Oils
a. Steam extraction part of extractor of essential oils is popular with the structure of basket-in-water.
b. Our extractor of essential oils operation part has adopted PLC or touch screen control system, this accords to customer’s demand.
3. Main Technical Datas of Extractor of Essential Oils
a. Power: 4.0kw, 380v/50Hz, Three Phase
b. Volume of Distillation Pot: 150L
c. Heating Area of Extraction Tank: 1.45M2
d. Condensing Area of Condenser: 1.25M2
e. Cooling Area of Cooler: 1.20m2
f. Vacuum Pressure for Distillation: 0.3mpa
g. Moisture Extraction Temperature: 50~100c
h. Power Of Electric Heater: 4 kw (Includes Oil Heating System)
i. Cooling From Tap Water
4. Features of Extractor of Essential Oils
a. By steam-distillation to reach the extraction of essential oils.
b. Easy operation. One people can operate Extractor of Essential Oils easily .
c. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.
d. Compact structure. It covers only about 1.5 square meter.
e. Tank wall treated: inside mirror-polished, outside honed.
5. Pictures of Extractor of Essential Oils
200L Extractor of Essential Oils
Temperature Control Cabinet of Extractor of Essential Oils
Detail of Extractor of Essential Oils
More detail of Extractor of Essential Oils
Oil-water Seperator for Extractor of Essential Oils
Raw Material of Extractor of Essential Oils
All kinds of plants can be the raw material of Extractor of Essential Oils
Final Product of Extractor of Essential Oils
Any question about Extractor of Essential Oils, please contact with us freely!
Thank you for interested in our Extractor of Essential Oils!
