HJ013-315 Motor Rotor Forming Machine
- 15 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | Shengli | Model Number | HJ013-315 | |
| Voltage | 220 v | Power(W) | 18.5 kw | |
| Dimension(L*W*H) | 4730x3800x5410 mm | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.injecting aluminum liquid into the motor rotor2.a PLC control
3.three operating modes of inch
It is specially designed for injecting aluminum liquid into the motor rotor, a PLC control, three operating modes of inch, manual and semi-automatic, one-by-one execute actions of slow, quick injecting, pressurizing and cutting off the pouring head. It's especially available for injecting Y-type motor rotors and similar motor rotors. The 400KN model mainly for injecting micro-motor rotors of fans and laundry machines without actions of three-step injecting and pouring head cut off. It is loaded with guard barriers to prevent the operator from burnt injury. With the features of reliability, easy to operate and high efficiency, it's good reputation in our customers. Nominal capacity: 400-10000KN Iron core: D50-D600mm
Contact Us
- Huzhou Machine Tool Works Co., Ltd.
- Contact namePaul Xu Chat Now
- Phone86-572-2129525
- AddressNo.336 Licun Road, Huzhou, Zhejiang
