Glass Fiber Reinforced Plastic Hydraulic Press

Glass Fiber Reinforced Plastic Hydraulic Press thumbnail-1
Glass Fiber Reinforced Plastic Hydraulic Press photo-1
US$ 8,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Shengli
Model Number:
YF71
Contact Supplier Request Quote Chat Now
Huzhou Machine Tool Works Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Shengli
Model Number YF71
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Stand-alone hydraulic station and electrical cabinet
2.Focused botton panel

It is mainly available for pressing glass fiber reinforced plastic such as SMC,BMC,DMC,GMC,LET-D etc. Providing four-column and straight side style with high strength and functions of quick ram descent, controllable multistage pre-pressing, pressurizing and micro-mould-open. It's the ideal solutions for applications of aviation and spaceflight, shipbuilding, automobile, architecture, petrochemical, energy, electronics and culture & spots industries.

Nominal capacity: 1000-60000KN



Standard Configuration:

1.Four-column type for including and below 500 ton, framed body type for including and above 630 ton with X-type rail guide.

2.Omron PLC and touch screen.

3.Pressure transducer.

4.Displacement transducer.

5.Excellent home-made pumps and valves.

6. Excellent home-made seal rings.

7.Schneider electrical parts.

8.Light-curtain protector in front of the press body.

9.Hydraulic station at the right of the press body for including and below 500 ton, at the top of the press body for including and above 630 ton.

10.Digital display of speed and pressure.

11.Ejecting outside the die.



Optional Accessories:

1.Movable working table.

2.Hydraulic float-rail and die-change bracket outside press body.

3.Die-change trolley.

4.Imported pumps and valves.

5.Imported seal rings.

6.Other brand electrical parts.

7.Die heating system.

8.Light-curtain protector at the back of the press body.

9.NC control of speed, pressure and temperature.

10.Control system of ejecting inside the die, loosing--core, vacuum and blowing knock-off.



Main Technical Data:



Item Unit YF71-63 YF71-100 YF71-200 YF71-315 YF71-400 YF71-500 YF71-630





Nominal Force  KN  630  1000  2000  3150  4000  5000  6300
Prepressing force  KN  250  315  630  1000  1250  2000  2500
mould-open Force  KN  125  250  400  630  800  1000  1250
Knock-off Force  KN  125  250  400  630  630  1000  1000
Opening Table Size LR  mm  570  720  930  1260  1300  1400  1600/2000
FB  500  630  900  1200  1300  1400  1600/1800
T-slot    22  22  28  28  36  36  36
Daylight  mm  800  900  1120  1250  1250  1500  1500/2000
Ram Stroke  mm  500  630  710  800  800  900  1100/1400
Knock-off Stroke  mm  200  200  200  300  300  300  300
Max.system pressure  Mpa  25  25  25  25  25  25  25
Quick descent speed  mm/s  120  120  120  150  180  180  200
Pre-pressing Speed  mm/s  5~25  5~25  5~20  5~20  5~20  5~20  5~25
Pressing Speed  mm/s  2~10  2~10  2~7  2~7  2~7  2~7  1~5
Mould-open Speed  mm/s  5~30  5~30  5~30  5~30  5~30  5~30  5~30
Ram Return Speed  mm/s  100  100  100  120  140  170  180
Slow Knock-off Speed  mm/s  5~30  5~30  5~30  5~30  5~30  5~30  5~30
Quick Ejecting Speed  mm/s  80  80  80  80  80  80  60
Press-body Type   Four-column        Framed



Item Unit YF71-800 YF71-1000 YF71-1250 YF71-1600 YF71-2000 YF71-2500 YF71-3000
Nominal Force KN 8000 10000  12500  16000  20000  25000  30000
Prepressing Force KN 2500 3150  3150  5000  6300  8000  10000
Mould-open Force KN 1250 1600  1600  2500  3150  4000  5000
Knock-off Force KN 1000 1000  1000  1600  2000  2000  2000
Opening Table Size LR mm 2000 2000  2200  2500/3000  3000  3200  3600
FB 1600 1600  1600  1600/1600  2000  2500  2500
T-slot   36 36  36  42  42  42  42
Daylight mm 1600 2000  2000  2000/1700  2500  2500  2500
Ram Stroke mm 1200 1400  1400  1500/1200  1500  1500  1500
Knock-off Stroke mm 300 300  300  300  300  300  300
Max.system Pressure Mpa 25 25  25  25  25 25   25
Quick Descent Speed mm/s 200 250  250  250  300  300  300
Pre-pressing Speed mm/s 5~25 5~25  5~25  5~25  5~25  5~25  5~25
Pressing Speed mm/s 1~5 1~5  1~5  1~5  1~5  1~5  1~5
Mould -open Speed mm/s 5~30 5~30  5~30  2~25  2~25  2~25  2~25
Ram Return Speed mm/s 180 180  180  180  180  180  180
Slow Knock-off Speed mm/s 5~30 5~30  5~30  2~30  2~30  2~30  2~30
Quick Ejecting Speed mm/s 60 80  80  80  80  100  100
Press-body Type   Framed
