Applications & Features
C-frame type,hydraulic system built-in with tidy appearance, optional of preset pressure or preset stroke, made for straightening shafts and sectional material, press-fitting sleeve parts, bending,embossing and drawing as well as pressing various plastic and powder wares. C-frame machine supplies easy approach to operate in three directions. Nominal capacity: 10-25000KN
Main Technical Data
| Item | Unit | YF30-2.5 | YF30-4 | YF30-6.3 | YF30-10 | YF30-16 | YF30-25 | YF30-40 | YF30-63 | YF30-100 | YF30-200 | YF30-315 | YF30-500 | |
| Nominal Force | KN | 25 | 40 | 63 | 100 | 160 | 250 | 400 | 630 | 1000 | 2000 | 3150 | 5000 | |
| Max.Working Pressure | Mpa | 8 | 12.5 | 16 | 20 | 20 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| Ram Stroke | mm | 125 | 200 | 200 | 250 | 320 | 350 | 400 | 400 | 450 | 450 | 450 | 1200 | |
| Throat Depth | mm | 110 | 125 | 180 | 250 | 250 | 280 | 320 | 320 | 320 | 350 | 350 | 1500 | |
| Daylight | mm | 210 | 360 | 360 | 450 | 520 | 560 | 600 | 650 | 710 | 710 | 710 | 1600 | |
| Table Size(LRxFB) | mm | 300x200 | 320x240 | 360x320 | 500x420 | 560x480 | 630x520 | 700x580 | 710x600 | 710x630 | 710x630 | 1000x650 | 2500x2500 | |
| Blanking Hole | mm | Φ80 | Φ80 | Φ80 | U100 | Φ100 | Φ145 | Φ125 | Φ165 | Φ80 | / | Φ170 | / | |
| Table Height above Floor | mm | 900 | 900 | 900 | 700 | 700 | 700 | 700 | 800 | 820 | 700 | 700 | 400 | |
| Ram Speed | Descent | mm/s | 38 | 38 | 55 | 45 | 45 | 115 | 63 | 115 | 110 | 180 | 180 | 130 |
| Work | 38 | 38 | 55 | 25 | 10 | 15 | 14 | 8 | 8 | 8 | 8~15 | 5~12 | ||
| Return | 100 | 100 | 140 | 130 | 80 | 120 | 96 | 105 | 90 | 150 | 120 | 100 | ||
| Overall Size | LRxFB | mm | 1105x555 | 1105x555 | 1295x595 | 1125x740 | 1215x790 | 1485x860 | 1540x860 | 1700x950 | 1900x860 | 1240x2540 | 1905x2245 | 4850x2500 |
| Height above Floor | 1720 | 1860 | 1900 | 1820 | 1985 | 2030 | 2164 | 2488 | 2705 | 3440 | 4190 | 7620/6000 | ||
| Motor Power | kw | 1.5 | 2.2 | 3 | 3 | 3 | 4 | 5.5 | 5.5 | 7.5 | 22 | 30 | 30 | |
FAQ ABOUT FOUR COLUMN HYDRAULIC PRESSES
Does welded beam easy deformation?
We treat it with tempering treatment to reduce internal stress.Besides, we also make casting beam.
What is the treating process of four column?
Four columns are made of 45# hot rolling round steel,then aligning,medium frequency hardening and chroming to ensure the precision,perpendicularity and glossiness.
The oil cylinder is important part,what if it broke?
We use forging cylinder which is forged by one 45# round steel,no welded.The broke rate is almost zero.
What about the electric system?
We use PLC electric control system with less line,easy maintenance and can programmable.
If part of the machine broke,does it easier to buy it in our country?
We can use customer appointed accessories if necessary.
Do you provide after service?
We provide technical service for life.
we are manufacturer of hydraulic press more than fifty years and can manufacture non-standard hydraulic press as your need( such as large worktable,deep slider stroke,multiple cylinder,high speed,double acting...)
