1000T High Speed CNC Hydraulic Press For T Pipe

Application & Feature

Manufacturing various T-pipe specifications, and gaining parts of 90 degrees or 135 degrees intersection angle as long as you alter the position between two side cylinders.

It has been made up to 4000 ton capacity with 300 MP a high-pressure unit, max. T-pipe diameter is 325,10S wall depth with carbon steel or stainless steel.

Stand-alone hydraulic and electrical system with PLC executes three operations of inch, manual and semi-automatic , featured with layout optimization, easy repair, reliable operation, high productivity and quality products.

Main Technical Data

1.Specifications mentioned above are subject to any change without notice.

2.The products can be tailored as customer's desire.

3.Letter A means triple-lateral cylinder layout, the left and the right side cylinders are opposite and the other at the rear side at 90º angle to each other. C represents bilateral cylinder layout, the left cylinder at 90º angle to the rear or the left cylinder at 135º angle to the rear. D indicates triple-lateral cylinder layout, the left and the right side cylinders are opposite and the other at the rear side at 90º angle to each other or 45º angle to the right. E bilateral cylinder layout, the left and the right side cylinders stand oppositely.

FAQ ABOUT FOUR COLUMN HYDRAULIC PRESSES

Does welded beam easy deformation?

We treat it with tempering treatment to reduce internal stress.Besides, we also make casting beam.

What is the treating process of four column?

Four columns are made of 45# hot rolling round steel,then aligning,medium frequency hardening and chroming to ensure the precision,perpendicularity and glossiness.

The oil cylinder is important part,what if it broke?

We use forging cylinder which is forged by one 45# round steel,no welded.The broke rate is almost zero.

What about the electric system?

We use PLC electric control system with less line,easy maintenance and can programmable.

If part of the machine broke,does it easier to buy it in our country?

We can use customer appointed accessories if necessary.

Do you provide after service?

We provide technical service for life.

we are manufacturer of hydraulic press more than fifty years and can manufacture non-standard hydraulic press as your need( such as large worktable,deep slider stroke,multiple cylinder,high speed,double acting...)
