Used 2.5 Ton Mini Hydraulic Press
US$ 500 - 3,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T
You May Like
-
Punching Machine, CNC Punching Machine, Punch Press Machine
-
Sheet Metal Punching Machine, Metal Punching Machine, Hydraulic Punching Machine
-
Manual Punching Machine, Hole Punching Machine, Hydraulic Hole Punching Machine
-
Hydraulic Press Machine 200 Ton, YF28 Double-action Hydraulic Press
-
2015 Hydraulic Bending Machine 300 Ton
-
YF28 CNC Hydraulic Sheet Bending Machine
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Shengli | |
| Model Number | YF30-2.5 | Voltage | 380 v | |
| Power(W) | 1.5 kw | Weight | Depend on Detail Model | |
| Dimension(L*W*H) | 1105x555x1720 mm | Certification | CE, SGS | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas | |
| Power Source | Hydraulic | Condition | New |
Product Description
Specifications
1.hydraulic system built-in with tidy appearanceing various plastic and powder wares
3.C-frame
C-frame type,hydraulic system built-in with tidy appearance, optional of preset pressure or preset stroke, made for straightening shafts and sectional material, press-fitting sleeve parts, bending,embossing and drawing as well as pressing various plastic and powder wares. C-frame machine supplies easy approach to operate in three directions. Nominal capacity: 10-25000KN
| Item | Unit | YF30-2.5 | YF30-4 | YF30-6.3 | YF30-10 | YF30-16 | YF30-25 | YF30-40 | YF30-63 | YF30-100 | YF30-200 | YF30-315 | YF30-500 | |
| Nominal Force | KN | 25 | 40 | 63 | 100 | 160 | 250 | 400 | 630 | 1000 | 2000 | 3150 | 5000 | |
| Max.Working Pressure | Mpa | 8 | 12.5 | 16 | 20 | 20 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| Ram Stroke | mm | 125 | 200 | 200 | 250 | 320 | 350 | 400 | 400 | 450 | 450 | 450 | 1200 | |
| Throat Depth | mm | 110 | 125 | 180 | 250 | 250 | 280 | 320 | 320 | 320 | 350 | 350 | 1500 | |
| Daylight | mm | 210 | 360 | 360 | 450 | 520 | 560 | 600 | 650 | 710 | 710 | 710 | 1600 | |
| Table Size(LRxFB) | mm | 300x200 | 320x240 | 360x320 | 500x420 | 560x480 | 630x520 | 700x580 | 710x600 | 710x630 | 710x630 | 1000x650 | 2500x2500 | |
| Blanking Hole | mm | Φ80 | Φ80 | Φ80 | U100 | Φ100 | Φ145 | Φ125 | Φ165 | Φ80 | / | Φ170 | / | |
| Table Height above Floor | mm | 900 | 900 | 900 | 700 | 700 | 700 | 700 | 800 | 820 | 700 | 700 | 400 | |
| Ram Speed | Descent | mm/s | 38 | 38 | 55 | 45 | 45 | 115 | 63 | 115 | 110 | 180 | 180 | 130 |
| Work | 38 | 38 | 55 | 25 | 10 | 15 | 14 | 8 | 8 | 8 | 8~15 | 5~12 | ||
| Return | 100 | 100 | 140 | 130 | 80 | 120 | 96 | 105 | 90 | 150 | 120 | 100 | ||
| Overall Size | LRxFB | mm | 1105x555 | 1105x555 | 1295x595 | 1125x740 | 1215x790 | 1485x860 | 1540x860 | 1700x950 | 1900x860 | 1240x2540 | 1905x2245 | 4850x2500 |
| Height above Floor | 1720 | 1860 | 1900 | 1820 | 1985 | 2030 | 2164 | 2488 | 2705 | 3440 | 4190 | 7620/6000 | ||
| Motor Power | kw | 1.5 | 2.2 | 3 | 3 | 3 | 4 | 5.5 | 5.5 | 7.5 | 22 | 30 | 30 | |
