Punching Machine, CNC Punching Machine, Punch Press Machine
- 80 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
- Professional High Precision Wide Application J23-25 cnc turret punching machines
- High Precision Wide Application J23-25 c frame punch press
- Professional High Precision Wide Application J23-25 hydraulics
- High Precision Wide Application J23-25 c frame fixed table punching machine
- Factory Sale High Precision Wide Application J23-25 construction material making machine
- High Precision Wide Application J23-25 scrap metal cutting machine for punching machine
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Shengli | Model Number: | YF27, YF28, YF30, YF32, YF41 |
Voltage: | 380 v | Power(W): | kw | Weight: | Depend on Detail Model |
Dimension(L*W*H): | mm | Certification: | CE,SGS | Warranty: | All life,1 year for free |
After-sales Service Provided: | Engineers available to service machinery overseas | Power Source: | Hydraulic | Condition: | New |
Product Description
Specifications
1. Good appearance2. High efficiency and low cost
3. Excellent hydraulic system
4. Easy operation and repair
5. CE,SGS
Huzhou Machine Tool Works Co., Ltd. (HMTW) was established in 1954, located at Huzhou Economic & Technical Development District by the south of Tai Lake, covers nearly an area of 150000m² including 65000m² building, well equipped with more than 200sets of heavy-duty cranes, NC floor boring-milling machines, NC machining centers, large-scale lathes and planers etc.
For decades, the company has succeeded in development of more than 50 series and 400 varieties of hydraulic presses with four-column, straight-side, C-frame and horizontal, widely applications to general-purpose, metal plate forming, bulk metal forming, pipe, powder ware, rubber and plastic ware, electric motor, vehicle wheel, special-purpose pressing, hot stamping for high-strength steel plate, interior high-pressure forming, automobile longitudinal beam, NC servo, precise punching, glass fiber reinforced plastics (SMC), carbon extruding, vehicle door edging, part straightening and glass ware etc. A lot of products are entitled with National Important New Product and Provincial Key Manufacture Industry First-set Product.
Applications & Feature:
YF27: It has the functions of metal sheet drawing, blanking and punching etc besides general operation, equipped with buffer facility for punching after deep-drawing or flanging after punching, widely available for automobile, motorcycle, electric appliance, petrochemical, rail transit, aviation and spaceflight etc, supplied with YF27 four-column and HJY27 straight-side, bus control technology and assembling many hydraulic presses into a production line. Loaded with upper hydraulic cushion, micro inching matching die and quick die change system etc.
1.This serial 4-column hydraulic press has a wide popularity, it can be applied into various compressing craft of plastic material, like bending, turn-up,sheet stretching,also it can applied into revising,press fitting. It has applied popular in abrasive material industry,fire-proof material.powder metallurgy and etc.If the machine is applied in the inputting or punching, the customer need to order the blanking cushion device to eliminate or ease the impacting and noise in the moment of broking the material.
2.This serial hydraulic press has independent motive structure and electric system. With the use of button central control, it can achieve three operating method as regulating (inching), manual and semi-automatic.
3.The working pressure, compressing speed, the stroke range of fast down stroking and slow down of this serial hydraulic press all can be regulated according the craft requirements; also it can achieve two craft method as fixed-pressure forming and fixed-distance forming. The craft of fixed-pressure forming can maintain pressure, defer and return stroke automatically. Maintaining pressure has two different choices as machine halt pressure maintaining and non-halt machine pressure maintaining.
Item | Unit | YF27-200 | YF27-315 | YF27-315 | YF27-400 | YF27-500 | YF27-500 | YF27-500 | YF27-630 | YF27-800 | YF27-1000 | YF27-1500 | YF27-3000 | |
Nominal Force | KN | 2000 | 3150 | 3150 | 4000 | 5000 | 5000 | 5000 | 6300 | 8000 | 10000 | 15000 | 30000 | |
Return Stroke | KN | 360 | 450 | 450 | 510 | 570 | 570 | 810 | 810 | 940 | 1060 | 1150 | 2450 | |
Ram Stroke | mm | 710 | 800 | 800 | 800 | 900 | 900 | 1100 | 1100 | 1000 | 1000 | 1200 | 1000 | |
Daylight | mm | 1120 | 1250 | 1200 | 1250 | 1500 | 1500 | 1500 | 1500 | 1600 | 1800 | 1800 | 2000 | |
Cushion Force | KN | 800 | 1250 | 1000 | 1600 | 2000 | 2000 | 2500 | 2500 | 4000 | 5000 | 4000 | 8000 | |
Cushion Stroke | mm | 250 | 300 | 350 | 350 | 400 | 400 | 400 | 400 | 400 | 400 | 500 | 400 | |
Ram Speed | Quick Descent | mm/s | 130 | 150 | 150 | 180 | 180 | 180 | 150 | 150 | 150 | 250 | 200 | 200 |
Work | 13-23 | 8-14 | 6-14 | 13-23 | 10-18 | 10-18 | 8-14 | 8-15 | 10-24 | 8-15 | 15 | 15 | ||
Return | 130 | 110 | 100 | 200 | 180 | 180 | 90 | 110 | 180 | 130 | 100 | 100 | ||
Cushion Speed | Ascent | mm/s | 60 | 40 | 50 | 60 | 45 | 45 | 30 | 35 | 50 | 50 | 50 | 40 |
Table Size | LR | mm | 930 | 1260 | 2200 | 1300 | 1400 | 2000 | 2500 | 2500 | 3200 | 3000 | 3200 | 4000 |
FB | 900 | 1200 | 1500 | 1300 | 1400 | 1600 | 1800 | 2200 | 2200 | 2000 | 2200 | 2500 | ||
Cushion Size | LR | mm | 600 | 900 | 1600 | 900 | 1050 | 1650 | 1950 | 1850 | 2300 | 2300 | 2400 | 3000 |
FB | 600 | 900 | 960 | 900 | 1050 | 1200 | 1200 | 1700 | 1550 | 1400 | 1650 | 1800 | ||
Overall Size | LR | mm | 2720 | 3200 | 3800 | 3900 | 4050 | 5640 | 5826 | 4400 | 6400 | 6000 | 6500 | 8500 |
FB | 2200 | 2200 | 3300 | 3600 | 3850 | 3100 | 2984 | 4000 | 3380 | 3200 | 4500 | 5000 | ||
Above Floor | 3630 | 4200 | 5230 | 4530 | 5020 | 5250 | 5590 | 6100 | 6050 | 6000 | 7000 | 7600 | ||
Motor Power | KW | 30 | 30 | 30 | 60 | 60 | 60 | 60 | 60 | 115 | 115 | 112 | 185.5 |
