Metal Cold Extruding Hydraulic Press Machine

Metal Cold Extruding Hydraulic Press Machine thumbnail-1
Metal Cold Extruding Hydraulic Press Machine photo-1
US$ 8,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Shengli
Contact Supplier Request Quote Chat Now
Huzhou Machine Tool Works Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name Shengli
Model Number HJY61
Voltage 380 v
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Cold-extruding metal parts at normal temperature
2.straight-side type and 8-point gib guided way with good stiffness

The series is designed for extruding cold and hot metal and with all of functions of cold and hot extrusion. Wholly-framed body press type, adjustable 8-fold guide way with high guide accuracy and retaining, stand-alone hydraulic station and electrical cabinet, optional of three operating modes of inch, manual and semi-automatic separately with preset stroke and preset pressure controls. Working pressure and stroke can be regulated in the specified range. With the features of reliability and high efficiency, it's the ideal solution for metal extruding applications.



Item Unit HJY61-100 HJY61-200 HJY61-315 HJY61-400 HJY61-500 HJY61-630 HJY61-800 HJY61-1000
Nominal Force KN 1000 2000 3150 4000 5000 6300 8000 10000
Return Force KN 160 240 300 510 570 1250 720 1300
Ejecting Force KN 200 200 400 500 630 630 1000 1500
Max.Working Pressure Mpa 25 25 25 25 25 25 25 25
Daylight mm 1000 700 700 805 1000 1250 800 1800
Ram Stroke mm 600 400 400 500 500 800 500 800
Ejector Stroke mm 200 200 200 200 200 350 200 400
Table Height above Floor mm 600 700 700 600 750 800 800 650
Ram Speed Quick Descent mm/s 160 160 160 180 150 200 200 140
Work 10-18 10-18 9-20 12-23 10-20 12-28 12-23 10-20
Return 150 150 150 130 160 140 200 120
Opening Table Size LR mm 620 620 700 850 1000 1200 1060 1600
FB 580 580 620 850 1000 1200 1350 1400
Overall Size FB mm 1750 1800 3000 3330 2400 2712 3855 3100
LR 2580 2940 2800 4100 3550 3550 5100 6200
Height above Floor 3470 3870/3490 4395/3765 4925/4315 5140/4550 6588/5818 6203/5480 7950/6350
Motor Power KW 11 22 30 22x2 22x2 45x2 45x2 55x2
