High effiency Trees Skin Peeling Machine, Wood log Peeling Machine
- 100 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T Credit Card
- wood debarker machine
- ring type wood debarker machine Ring Debarker for Wood debarkers
- Hot Sale Wood log debarking machine wood log peeler for price
- High quality wood peeling machine poplar peeling machine for sale
- big capacity Eucalyptus Wood Peeling Machine wood peeler tree debarking machine
- wood bark peeling machine wood peeler
Product Details
Condition: | New | Wood Diameter Range: | 15-320mm | Peeling Rate: | 95% |
Wood Loss Rate: | 5% Max | Wood Length Range: | 6~12m | Place of Origin: | Henan, China |
Brand Name: | Auris | Model Number: | ASP-6S | Voltage: | 380V |
Power(W): | 7.5*2KW | Dimension(L*W*H): | 6300*1310*1550mm | Weight: | 3-4t |
Certification: | ISO CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
high effiency Trees Skin Peeling Machine, Wood log Peeling Machine
Main features:
High Peeling Rate Wood Log Debarker Machine For Sale - Buy Wood Log Debarker Machine,Wood Debarkering Machine,Wood Log Debarker Machine Product on 1. General introduction of wood log debarker machine :
a. Wood debarking machine use open silo, from one side feeds materials, from the other side discharge. The assembly line operation to overcome the existing peeling machine feed, discharge, storage shortcomings and with high efficiency.
b. Due to the impact of gear teeth on wood, the wood logs in the bin for circulating movement, so stripping efficiency is high. The peeling rate could reach 95%.
Wood debarker/Barking/peeler machine is suitable for large,medium and small paper mills, pulp mill, wood factory, wood processing plant, forestry factory, timber yard, artificial board factory (such as plywood plant, medium density fiberboard factory etc.).
2. Operation of wood log debarker machine :
a. Put the log and tree branches into the rotary drum,close the feeding baffle,then start the machine,with clockwise operation,the cutter will strip wood skin.
b. Fifteen minutes later,stop the machine,open discharging baffle, then start the machine and counterclockwise run two minutes,the peeled wood can be automatically sent out by roller.
Main parameters:
specifications | 6m single roller | 9m single roller | 12m single roller |
Capacity(ton/h) | 5-10ton | 10-15ton | 15-25ton |
motor power(kw) | 7.5*2 | 7.5*2 | 7.5*2 |
Length(mm) | 6300 | 9000 | 12600 |
Width(mm) | 1310 | 1500 | 1500 |
Heighth(mm) | 1550 | 1700 | 1700 |
Weight(Ton) | 3ton | 4ton | 7.5ton |
specifications | 6m double roller | 9m double roller | 12m double roller |
Capacity(ton/h) | 7-15ton | 15-25ton | 25-30ton |
motor power(kw) | 7.5*2 | 7.5*2 | 7.5*2 |
Length(mm) | 6300 | 9000 | 12600 |
Width(mm) | 1310 | 1500 | 1550 |
Heighth(mm) | 1550 | 1700 | 1650 |
Weight(Ton) | 4ton | 5ton | 8ton |
Pictures:
