Original 6*4 SHACMAN Tractor ss

Name: Original 6*4 SHACMAN Tractor ss
Brand: SHACMAN
SKU: 141326350
Availability: InStock

US$ 30,000 - 370,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Horsepower:

351 - 450hp

Drive Wheel:

6x4

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Horsepower 351 - 450hp

Drive Wheel 6x4

Transmission Type Manual

Emission Standard Euro 2

Fuel Type Diesel

Brand Name SHACMAN

Size 6825*2490*3624

Gross Vehicle Weight 8800 kg

tractor truck

1. Weichai engine, No.1 engine in China
2. MAN techonogy
3. FULLER transimission
4. TUV, SGS certificate

Model	SX4254NV294
Drive type	6×4
Weight
Complete kerb mass (kg)	8800
GVW (kg)	25000
GCW(kg)	40000
Dimensions
Max.length	6825
Max.width	2490
Max.heigh	3624
Front / Rear overhang (Chassis)	1525/725
Wheel base(mm)	3175+1400
wheel track(front/rear)(mm)	2036/1800
Performance
Max.speed (km/h)	99
Min.turning circle(m)	2.65
Min.ground clearance(mm)	1420
Approach / Departure angle (°)	20/66
Max.gradeability(%)	33
Engine
Brand	WEI CHAI
Model	WP10.340E32
Power(kw/HP)	250/340
Max.Torque (N.m )/rpm	1800/1000-1400
Displacement(L)	11.596
Emmission Standards	Euro Ⅲ
Transmission
Make	FAST
Model	12JSD160TA
Control type	manual
Gear Shift	12-forward and 2reverse speeds
Clutch
Type	Single plate,diaphragm spring
Diameter (mm)	φ430
Action	mechanical type,hydraulic and pneumatic operation
Axles
Brand	HANDE
Front axle	7500kg
Rear axle	13000kg(each other) Double reduction driving axle with inter-wheel differential and differential lock.
Tyres
Type (Standard)	12.00-22.5
Fueltank
Tank capacity (L)	400
Cab
Type	MAN F3000, Long-hight roof
