Tower Crane luffing boom QTZ315--CANMAX

Specifications

16 ton Crane machine price QTZ315--CANMAX
1. work span: 70m
2. independent height: 53m
3. max.lifting capacity: 16T

                                                               CANMAX

As leading supplier for tower crane with 20 years development, we-CANMAX-win many buyers from  all over the world such as the Middle East, South Asia, Africa, Russia, South America and many other countries. Stable supurior quality and most competitive price can be assured from us.





1. CANMAX tower crane:

1. Developed by us combined with advanced international technology in tower crane industry.

2. Self-telescoping, top slewing and trolleying on horizontal jib.

3. Complete safety devices makes an excellent performance.

4.  Easy to assemble and disassemble with a pin system.

5.  Advanced technology applied in the mechanisms and control system.

6.  High reliability and easy maintenanc.



2. main technical parameters for CANMAX tower crane:

No	Name of parameter		Unit	Value
1	Max. rated lifting capacity		t	16
2	working span		m	70
3	Independent Height		m	53
5	Max.Height		m	301
6	Wall-attached Frame			11
7	Main Material			L1402×16(Angle steel welding)
8	Hoisting Speed		m/min	0-120
9	Mini.Stabilizing Falling Speed		m/min	2
10	Slewing Speed		r/min	0-0.7r/min
11	Traveling Speed		m/min	0-0.8
12	Climbing Speed		m/min	0.46
13	Motor Total Power		kw	117.5
14	Independent Structure Weight		kg	89300
15	Counter Weight		t	27.75



4. Production line for tower crane:

5. Certificate for tower crane



6. Other infomation:





7. Main markets for tower crane:
