XZ320B horizontal directional drilling-rig

Specifications

1.Strong power;
2.Dual-speed power unit;
3.Rubber crawler;
4.Floating vice;
5. Automatic loading and unloading of drill stem

Technical specifications

Product model: XZ320B horizontal directional drilling rig

Producer: Xuzhou Xugong Foundation Construction Machinery Co., Ltd

The XZ320B horizontal directional drilling rig has a compact structure and decent appearance. Its main technical performance parameters have reached the domestic advanced level. The main parts and components and corollary parts are of the world famous brand, ensuring the sound reliability of the whole machine.

A. Technical features

Strong power: The 160kW engine ensures that the drilling rig can pave the pipes under various complex ground conditions.

Dual-speed power unit: The low drilling and pulling speed ensures the successful construction. The power unit can accelerate the sliding speed after the drill stem is removed, so that the auxiliary work time is reduced and the work efficiency is enhanced.

Rubber crawler: The influence of this kind of crawler on the road, lawn and sight spot is smallest.

Floating vice: The proprietary floating vice of the Company shall be adopted, which can prolong the service life of drill stem effectively.

Automatic loading and unloading of drill stem: The automatic drill stem loading and unloading device can boost the work efficiency, and reduce the work intensity of operators and the number of construction workers.

Automatic anchoring: The drilling and pulling of anchor rod is driven hydraulically and controlled by the cylinder and the low-speed and high-torque motor. It is easy and convenient to operate.

Easy operation: The rotation, pushing and pulling of power unit are controlled separately. The whole machine is easy to operate so that the operators can learn how to operate the drilling rig after a short-period training



B. Main technical parameters





C. Configuration of main components



D. Structure and function of main compositions

XZ320B horizontal directional drilling rig is an integral device. The whole machine is composed of the chassis, power unit, drill stand, automatic drill stem loading and unloading device, anchor device, engine system, vice, hydraulic system, electrical system, slurry system and other components.

E. Optional parts for users

1. Drill stem and drill tool

The drill stem produced by Hebei Xuanhua, Wuxi Mineral Exploration Machinery or other producers can be selected. The cutting-type or squeezing-type expansion head with a diameter of 200mm~800mm can be selected.

2. Guide system

DCI wireless guide system can be selected.

3. Slurry mixing and distributing system

This system is composed of the engine, sewage pump, slurry tank and swell soil mixer. The capacity of slurry tank can be 2m³ or 3m³ dependent on the user’s needs.

F. On-board technical documents

The following technical documents are provided for XZ320B horizontal directional drilling rig:

Packing list

Certificate of conformity

Operation instructions

User's manual of engine

Operation instructions of slurry pump

Note: The products will be improved along with the technical advancement and the difference will be defined during ordering.
