SR200M Rotary Drilling Rig

Name: SR200M Rotary Drilling Rig
Brand: SANY
SKU: 141325532
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Place of Origin:

Shanghai, China

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Place of Origin Shanghai, China

Brand Name SANY

Model Number SR200M

Usage Other, dig hole on the earth

Specifications

SR200M Rotary Drilling Rig
RIg easily transported
Quick installation
Long service life

SR200M Rotary Drilling Rig

Multi-function: drilling with Continuous Flight Auger (max.drilling dia. Φ800mm and max. drilling depth 20m) or with Kelly system (max. drilling dia. Φ 1800mm and max. drilling depth 60m) after replacing related components;
Dry drilling without slurry circulation to facilitate drilling with fewer accessories and to avoid pollution;
The rig owns a high drilling efficiency due to the rotary drive with large output torque;
Auger cleaner to reduce labor intensity;
Isuzu AA-6HK1XQP intercooler diesel engine owns the functions of load-sensing and output power autoadjusting; auto accelerating/decelerating function, fuel consumption can be reduced by 5-10%;
Embedded system based on work mechanism controller and perfect CAN-BUS technique to take full charge of whole machine monitoring;
Hydraulic pump, motor, valve and joint are introduced in well-known brands to ensure high reliability of system; main oil circuit adopts advanced negative control technology and auxiliary oil circuit adopts load sensitive control system, which assures the optimal match of output power and load under all kinds of operating conditions;
Meet the standards of city construction law due to its low noise, slight vibration and little pollution during drilling
