3.5T Telescopic Handler1. Deutz or Perkins engine, powerful force
2. DANA axle
3. Max. lifting height: 13.8m
3.5T Telescopic Handler
Forklift Truck is a kind of Multi-functional engineering machinery .It can be used for lift and carry, with good stability and efficiency. It has compact frame, flexible operation , sensitive lift, automatic adjustment ,high carrying capacity.
Dopt the Cummins engine which is powerful and with low maintenance. Reach Europe III(EPA Tier3) exhaustion standard, big torque force.
Equipped with power transmission, compact structure, high rigidity.
With articulated frame, small turning radius.
wheel drive, steering by front wheel, and so on.
The driver′s cabin is furnished with the system of the air conditioner, It is safe and comfortable, and the visual field is broad. It adopts shock attenuation, which improved the comportableness of the operating
Fully sealed wet multi-disc brakes in the wheel heads are protected from environmental influences.
Multi-function instrument can be chosed..It is a kind of machinery which is suitable for lifting and carrying in narrow ground.
| model | XT670-140 | ||
| Description | Unit | Specificatons | |
| Overall dimensions(L*W*H) | mm | 6290×2450×2725 | |
| Working weight | kg | 10500 | |
| min.ground clearance | mm | 450 | |
| Wheel base | mm | 3250 | |
| Tread | mm | 1977 | |
| Engine Model | PERKINS/1104D-44T//Duzts TD226B-4IG2 | ||
| Rated power | kw | 74.5 | |
| Rated speed | r/min | 2200 | |
| displacement | L | 4.4 | |
| No.of cylinder | 4 | ||
| Max. speed | km/h | 35 | |
| Fork length | mm | 1200 | |
| Rear | mm | 1190 | |
| Departure angle | ° | 36.4 | |
| Min.turning radius | mm | 4238 | |
| Max. climbing capacity | ° | 26.5 | |
| foot brake/brake oil pressure | Mpa | wet type/4.4 | |
| hand brake | wet type/4.4 | ||
| working specs | outriggers on ground | outriggers are not ground | |
| Maximum lift capacity | Kg | 3500 | 3500 |
| Lift capacity to full height | Kg | 2269 | 1350 |
| Lift capacity at full reach | kg | 453 | 225 |
| Lift height | mm | 13800 | 13500 |
| Reach at maximum lift height | mm | 1330 | 1955 |
| Maximum forward reach | mm | 8830 | 9457 |
