Zoomlion Container Face Crane
Negotiable
/ Set
1 Set(Min. Order)
- any port in China
- T/T
You May Like
Product Details
| Place of Origin | Hunan, China | Brand Name | ZOOMLION | |
| Model Number | ZLJCRS45-5 |
Product Description
Specifications
Excellent performance on the loading, stacking and horizontal transporting of the standard containers of 20inch and 40inch.This machine owns many distinct advantages including a beautiful outlook, high efficiency, loading drive with whole body, stable power output, strong safety function, comfortable driving condition, easy operation, so it is a perfect machine for container loading and stacking. It can be applicable for port, transfer station and railway station.
Main Parameters:
| Working performance specification | Max. lifting capacity | The 1st row: Loading center, 1970 mm 1-4 layer: 45000kg, 5th layer: 43000kg |
The 2ed row: Loading center 3820 mm 1-4 layer: 31000kg, 5th layer: 30000kg | ||
| The 3rd row: Loading center 6320 mm 1-3 layer: 15000kg, 4th layer: 14500kg | ||
| Max. lifting height | 15100mm | |
| Lifting speed | 0.42m/s-0.25m/s | |
| Min. turning radius | 8000mm | |
| Max. grade-ability | 39%-32% | |
| Driving speed | 25km/h-21km/h 25km/h-21km/h(reversing) | |
| Dimension Specification | Overall dimension | 11200 ×4200 ×4850(mm) |
| Total weight | 71000 kg | |
| Mass Specification | Engine | Volvo-TWD1240VE |
| Transmission | DANA Clark | |
| Axel | KESSLER |
