33m ZOOMLION Climbing Concrete Placing Boom HGC33D

Name: 33m ZOOMLION Climbing Concrete Placing Boom HGC33D
Brand: ZOOMLION
SKU: 141324400
Availability: InStock

US$ 95,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hunan, China

Brand Name:

ZOOMLION

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hunan, China

Brand Name ZOOMLION

Model Number HGC33D

Specifications

1.floor climbing and tunel climbing are optional
2.CIFA technology Boom design
3.Hydraulic system from Germany Roxth

Main technical parameter

Model			Units	HGC33D
Performance	Max.radius of placing boom		m	33
	Freestanding height (to the joint between the end of the boom and swivel table)		m	24/30
	Boom articulation		°	365
	Slewing brake		/	always close
	Working temperature		°C	-5°C~40°C
	Total weight		kg	23500
	Counter weight		kg	/
	Power		/	380V/50HZ
Motor	Model		/	Y2-160L-4-B35
	Power		kW	15
	Safety grade		/	IP54
	Insulation grade		/	F
Hydraulic system	Pressure		MPa	33
	Flux		l/min	16.8
Hydraulic oil	Circumstance temperature 5°C-48°C		/	Stand oil Co., DTE25
	Circumstance temperature -20°C-5°C		/	Stand oil Co., DTE24
Control mode			/	Short-haul Control /radio remote control
Pipeline cleaning			/	Wet cleaning/Dry cleaning
Structure of tower body			/	Tubular column
Section of tower body			m×m	0.75×0.75
Boom	Shape		/	Three hydraulic foldable arms
	Inner diameter of pipeline		mm	DN125
	End hose		″×mm	5″×3000/4000
	1st section	Length	m	14.87
		Articulation	°	0°~90°
	2nd section	Length	m	9.57
		Articulation	°	0°~180°
	3rd section	Length	m	8.56
		Articulation	°	0°~180°
	4th section	Length	m	/
		Articulation	°	/
Climbing	Climbing mode		/	By hydraulic cylinder climbing
	Interval of climbing		m	0.52
	Floor frame		/	Hole prepared in floor
	Shaft frame		m	Hole prepared in floor 2.0~2.7
	Min.Interval of climbing frame	Climbing	m	3.0
		Placing concrete	m	6.0
		Rest	m	6.0

Configuration name		Configuration items
configuration	Placing boom	ZOOMLION
	Tubular column	ZOOMLION
	Swivel reducer	Italy Brevini or American Dianamic
	Climbing device on floor	standard equipment
	Climbing device in elevator well	Option
	Fixed base	standard equipment
	Securing weight base	Option
	Wireless remote control	standard equipment

Hydraulic system configuration

Number	Name	Brand or origin
1	Boom oil pump	Shanghai Electric
2	Electromagnetic directional valve	Rexroth
3	High pressure filter	LEEMIN
4	Return filter	LEEMIN
5	Balance valve	OIL CONTROL
6	Slewing control valve	HAWE
