Help Center50hp Wheel Tractor LYH500
US$ 10,000 - 13,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Wheel Tractor
By wheel
2WD
Usage
Farm Tractor
Brand Name
CANMAX
Model Number
LYH500
Place of Origin
Henan, China
Specifications
50hp wheel tractor LYH5001.Good quality, low price.
2.Professional service.
3.Drive type:4*2.
50hp wheel tractor LYH500
| Tractor model | LYH500 | LYH504 | |
| Pattern | 4×2(Two turn actuation) | 4×4(Four-wheel drive) | |
| Outlook sizemm | Long (in front of belt counterweight) | 3579 | 3579 |
| Width | 1750 | 1750 | |
| High (to air vent) | 2130 | 2130 | |
| Spread of axies (mm) | 1946 | 1990 | |
| Front wheel tread (mm) | 1200-1500(Commonly used 1300) | 1250 | |
| Rear wheel tread (mm) |
1200-1500(Commonly used 1300) | ||
| Smallest gully (mm) | 400 | 325 | |
| Agronomy gully (mm) | 450 | 375 | |
| Changes radius (mm) | Unilateral brake | 3.1 | 3.4 |
| Unilateral brake | 3.5 | 4.1 | |
Complete machine quality (kg) |
Structure quality | 1665 | 1890 |
| Smallest use quality | 1840 | 2080 | |
| First disposes | 108 | 144 | |
| Latter disposes | 360 | 360 | |
| Fixed force of traction (KN) | 9 | 12 | |
| Engine model |
498BT | ||
| Demarcation power (KW) | 36.8 | ||
| Coupling |
10 inch dry list function or double-acting | ||
| Gear box |
4× (2 1) keeps off the composition type meshing wrap to shift gears | ||
| Speed range |
2.4-31.9 | ||
| Central rotation | Screw round bevel gear pair | ||
| Differential device | Two planetary gears, closed type | ||
| Differential lock | Plug type | ||
| Final transmission |
Planet gear type | ||
| First driving axle | The entire seal bevel gear type (four-wheel drive type uses) | ||
| Transfer case |
The straight tooth cylindrical gears (four-wheel drive type uses) | ||
| Front wheel tire specification | 6.0-16 8.3-20 | ||
| Trailing wheel tire specification | 12.4-28 | ||
| Diverter pattern | Mechanical or the entire hydraulic pressure changes | ||
| Brake labor |
Biplate oil bath plate brake (mechanical type) | ||
| Hoist pattern | The half minute sets at the type | ||
| Ploughs the deep control mode | Strength, position control and fluctuation control | ||
| Suspension unit pattern |
Postpositioned three point suspension | ||
| Dynamic output speed of spindle (r/min) | 540/760 | ||
