Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Certificate CE
Brand Name LOVOL
Model Number TD750H
Place of Origin Shandong, China

Specifications

75 hp wheel tractor
1. Excellent quality,competitive price.
2. Drive type:4*2.
3. World famous brand, professional service



LOVOL  TD750H Wheel Tractor



1. The U.S. DANA front driving axle is optional;
2. Germany Luk clutch and STABILUS hood gas spring have a high reliability;
3. The use of flat floors, hanging pedals, side manipulation, 16+8 shuttle shift transmission, various gear selections and optional 8+8, 8+4 and 16+8 crawling gears, and 16+16 synchronized shuttle shift model, can provide a reasonable velocity distribution, and a good operating adaptability;
4. The 145-liter lower large fuel tank has a long operation time;
5. The U.S. ACTUANT combination instruments are optional;
6. EC, EPA and GOST certification models are available;
7. The optional models with stepless and adjustable tread have a good operating adaptability;
8. The optional widened tread with a high ground clearance can achieve intertillage, spraying, laminating and other field operations.



Drive type 4*2
Wheelbase (mm) 2366
Track(front/rear) regulating method Step/stepless
Min.operating weight (without cab)(kg) 4090
Counterweight (max) (front/rear) ——
Theoretical speed of each gear(forward/reverse) 6.74-33.48/10.26-34.45;0.46-6.93/0.62-2.14;1.57-7.81/2.39-8.04
Engine type In-line, four-stroke
Cylinder number 4
Stroke 127
Engine rated power kW@rpm 55
Air cleaner type Dry or wet type
Max. Torque@ revolving speed (rpm) 263@1500~1700
Fuel tank capacity (L) 145
Type of steering gear Cycloid orbitrol steering gear
Clutch type dry type,double action
Gearbox shift mode Shift sleeve
Final transmission mode(front/rear) Single-stage spur gear type, outboard on both sides of the rear axle casing
Tire Model (front/rear) 9.5-32/12-38
Type of linkage Three point rear linkage
Lift capacity(610mm point))kN Ordinary Riser≥15;Forced Riser≥20
Type of PTO shaft Rear separated type
Outer diameter of PTO shaft spline φ35/φ38
Hydraulic output flow (L/min) 37/47
Overall dimension(L * W * H) 4530*2610*3180
Track(front/rear) 1385~1685/1608~1996
Min.Ground clearance(mm) 790
Min.operating weight (without cab)(kg) --
Gears(forward/reverse/creeper) 8+4/16+8 shuttle type /16+8 creeping
Brand Lovol Power
Intake mode Supercharged
Bore 100
Displacement(L) 4
Rated speed 2200
Type of cooling system Water-cooled (or water intercooling or air intercooling)
Specific fuel consumption at rated conditions (g/kW.h) ≤248
Type of steering system Hydraulic steering
Type of braking system Wet type, disc type, static hydraulic control
Gearbox type Two-axis mechanical gearbox
Type of central transmission Spiral bevel gear type
Frame type Frameless
Type of hydraulic suspension system Open-center, semi-separated or separated type
Linkage classes Class II
Regulating mode Semi-separated lifter: force and position combination control; Separated raiser:depth control and floating control
The number of PTO shaft splines 6 splines/8splines
PTO shaft speed 540/1000(760/1000,540/760,760/850)
