Self Propelled Sessior Lift CMJC0812 10M

Name: Self Propelled Sessior Lift CMJC0812 10M
Brand: Canmax
Price: USD $10,000 - 60,000 / Set

FOB Price

USD $10,000 - $60,000 / Set

1 Set(Min.Order)

Product Details

Place of Origin:	Shanghai, China	Brand Name:	Canmax	Model Number:	CMJC0612
Lift Mechanism:	Scissor Lift	Lift Drive / Actuation:	Hydraulic	Power:	/
Rated Loading Capacity:	450Kg	Min. Lifting Height:	2.35m	Max. Lifting Height:	10.1m
Table Size:	2.25 m x 1.15 m x 1.1 m	Overall Dimensions:	2.391.151.96m	Weight:	2490kg
Certification:	CE ISO	Warranty:	1year	After-sales Service Provided:	Engineers available to service machinery overseas

Self Propelled Sessior Lift CMJC0812 10M

Product Description

Models	GTJZ0812
Dimensions
Platform height max.	26.6 ft (8.1 m)
Working height max.	33 ft (10.1 m)
Platform extended	3 ft (0.9 m)
Length - stowed	7.84 ft (2.39 m)
Width - stowed	3.77 ft (1.15 m)
Height - guardrail folded	6.43 ft (1.96 m)
Height - guardrail unfolded	7.7 ft (2.35 m)
Height - guardrail fixed	7.7 ft (2.35 m)
Wheelbase	6 ft (1.85 m)
Ground clearance	0.33 ft (0.1 m)
Platform size (LWH)	7.4 ft * 3.77 ft * 3.6 ft (2.25 m1.15 m1.1 m)
Productivity
Max. platform occupancy	2 (indoor), 2(outdoor)
Lift capacity	992 lbs (450kg)
Driving speed - stowed	0~3.2 km/h
Driving speed - raised	0~0.8 km/h
Gradeability	25%
Turning radius - inside	0 ft (0 m)
Turning radius - outside	7.7 ft (2.35 m)
Raising / Falling speed	30s~35s /35s~40s
Controls	Proportional
Drive &steer model	2WD, front -wheel
Brake	2 rear-wheel
Tire	380 mm * 125 mm/solid
Power
Power source	24V DC (4*6V, 225Ah batteries)
Hydraulic system tank vol.	18 L
Power	3 KW
Weight
overall weight ( indoor/outdoor )	5490 lbs (2490 kg)
Standards Compliance	CE/ ISO/ ADR/ ARAMCO

lifting machinary
