30m Telescopic Boom Self-propelled Aerial Work Platform
Specifications
30m Telescopic boom Self-propelled aerial work platform1.Platform height 30.4m
2.Lift capacity 480kg
3.Weight 18670kg
30m Telescopic boom Self-propelled aerial work platform
Item | Measurement | Item | Measurement |
Dimensions | Productivity | ||
Overall length(stowed) | 13M (43ft) | Platform height max. | 30.4M (100ft) |
Overall width(stowed) | 2.49M (8ft) | Working height max. | 32.4M (106ft) |
Overall height(stowed) | 3.08M (10ft) | Horizontal reach max. | 22.9M (75ft) |
Ground clearance | 0.25M (0.8ft) | Turntable rotation | 360°continuous |
Wheelbase | 3.66M (12ft) | Platform rotation | 160° |
Overall weight | 18670kg (4WD) | Platform Load capacity | 340kg (non-restricted) |
480kg (restricted) | |||
Platform Size (L*W*H) | 2.44*0.91*1.1M (8ft*3ft*3.6ft) | Grade ability | 42% (4wd) |
Platform levelling | Automatic | Turning radius(outside) | 5.57M (18ft) |
Tire specification | 12.00-20 | Turning radius(inside) | 2.56M (8ft) |
Tire type | Solid | Turntable tailswing | 1.82M (6ft) |
Power | Max. Driving Speed | 4.4KM/H | |
Hydraulic tank vol. | 200L | Driving Speed (stowed) | 0~4.4km/h |
Hydraulic system vol. (inc. the tank) | 300L | Driving Speed (extended) | 0~1.1km/h |
Fuel tank vol. | 150L | Max allowable wind force | 12.5m/s |
Control voltage | 24V | Max allowable slope | 3° |
Engine | Original Cummins B3.3 80hp | Max noise on normal use | 82dB(A) |
Drive & steer model | 4WD*4WS | Max allowable side force | 400N |
