8m Scissor Lift

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
8m Scissor Lift thumbnail-1
8m Scissor Lift photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
SINOBOOM
Model Number:
GTJZ08
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name SINOBOOM
Model Number GTJZ08
Lift Mechanism Scissor Lift
Rated Loading Capacity 250kg
Max. Lifting Height 7.9m
Overall Dimensions 2.3mx0.77mx1.1m
Weight 2180kg

Specifications

8m Scissor lift
1.Platform height 7.9m
2.Lift capacity 250kg
3.Weight 2180kg

8m Scissor lift

Major specification

GTJZ08

Measurement



Platform height

7.9m(26ft)

Working height

9.9m(32ft)

Overall width

0.77m(2.5ft)

Stowed height

2.38m(7.8ft)

Overall length

2.48m(8.1ft)

Platform size (L*W*H)

2.3mx0.77mx1.1m

Extension outreach

0.9m(3ft)

Performance



Platform capacity

250 kg

Wheelbase

1.88m

Ground clearance

0.09m

Travel speed--stowed

0~3.2km/h

Travel speed--raised

0~0.8km/h

Lift/Down speed (no load)

38/45s

Control

24V DC

Platform

Steel

Drive

2wd, front wheel

Disc brake

2 rear wheel

Max. wind speed

12.5m/s

Gradeability--stowed

25%

Turning radius-inside

0

Turning radius-outside

1.98m

Tire

Solid non marking

Tire dimension

406*125mm

Hydraulic tank

13L

Hydraulic System Volume

16L

Hydraulic system pressure

21 Mpa

Battery voltage

6V*4 / 225AH

Charger voltage & frequency

190~250V 50Hz

Charger output

30A auto-timing

Weight

2180kg

8m Scissor lift8m Scissor lift
