10m Scissor Lift

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.
10m Scissor Lift thumbnail-1
10m Scissor Lift photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
SINOBOOM
Model Number:
GTJZ10
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name SINOBOOM
Model Number GTJZ10
Lift Mechanism Scissor Lift
Rated Loading Capacity 450kg
Max. Lifting Height 9.8m
Overall Dimensions 2.55mx1.15 mx1.1m
Weight 2488kg

Specifications

10m Scissor lift
1.Platform height 9.8m
2.Lift capacity 450kg
3.Weight 2488kg

10m Scissor lift



Major specification

GTJZ10

Measurement



Platform height

9.8m(32ft)

Working height

11.8m(39ft)

Overall width

1.15m(3.8ft)

Stowed height

2.4m(7.9ft)

Overall length

2.55m(8.4ft)

Platform size (L*W*H)

2.55mx1.15 mx1.1m

Extension outreach

0.9m(3ft)

Performance



Platform capacity

450 kg

Wheelbase

2.12m

Ground clearance

0.09m

Travel speed--stowed

0~3.2km/h

Travel speed--raised

0~0.8km/h

Lift/Down speed (no load)

60/67s

Control

24V DC

Platform

Steel

Drive

2wd, front wheel

Disc brake

2 rear wheel

Max. wind speed

12.5m/s

Gradeability--stowed

25%

Turning radius-inside

0

Turning radius-outside

2.35m

Tire

Solid non marking

Tire dimension

406*125mm

Hydraulic tank

13L

Hydraulic System Volume

16L

Hydraulic system pressure

21 Mpa

Battery voltage

6V*4 / 225AH

Charger voltage & frequency

190~250V 50Hz

Charger output

30A auto-timing

Weight

2488kg

10m Scissor lift10m Scissor lift10m Scissor lift
