Peanut Grader Processing Production Line

Peanut Grader Processing Production Line thumbnail-1
Peanut Grader Processing Production Line thumbnail-2
Peanut Grader Processing Production Line thumbnail-3
Peanut Grader Processing Production Line photo-1
Peanut Grader Processing Production Line photo-2
Peanut Grader Processing Production Line photo-3
US$ 3,500 - 7,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
XLFY
Contact Supplier Request Quote Chat Now
Qingdao Wolong Peanut Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name XLFY
Model Number XLFY800-4-6
Type Sorter
Voltage 380V
Power(W) 2.2KW
Certification ISO9000
Warranty 12months
After-sales Service Provided Engineers available to service machinery overseas

Wolong Peanut Grading Machine/ Peanut Machine

grain,peanut processing line

2-6 levels peanut screening machine/peanut grading machine/Peanut classifier

This machine is absorbed the advantages of similar products at home and abroad,

with compact structure, reasonable, high efficiency, save energy consumption,

easy to use the characteristic such as being reliable, applicable in selected peanut kernels,

by a select can achieve precise classification standard. The sprocket, chain drive push rod,

sieve body smooth reciprocating screening, the screen piece made with iron plate punching,

each layer sieve body are returned to the disc, can make the material in the screen piece by the whole process

above screening, and clear materials in the halfway or front screen that is caused by the classification is not clear into

the disadvantages,and each layer sieve bottom after all have certain lists, facilitate the material flow smoothly.

Main parameter of the machine:





NO. Model processing capacity MT/H after insallation dimension(m) Power(KW) frequency conversion screen sheet
1 80-2-7 1

3.5*1.12*2.7

 6.5*2*3.2

 1.5   20
2 80-3-7 1.5

3.5*1.12*2.6

 6.5*2*3.2

 1.5   30
3 80-4-7        2

3.5*1.5*1.7

 6.5*2*3.5

 1.5   50
4 80-5-7       2.5

3.5*1.12*1.9

 6.5*2*3.6

 2.2   70
5 80-6-7       3

3.5*1.12*2.15

  6.5*2*4

 3   80
6 100-3-7         2

3.6*1.3*2.2

7.5*2.3*3.2

 1.5   30
7 100-4-7        3

3.6*1.3*1.7

 7.5*2.3*3.5

 2.2   50
8 100-5-7       3.5

3.6*1.3*2.1

 7.5*2.3*3.9

 3   70
9 100-6-7        4

3.6*1.3*2.4

7.5*2.3*4.2

 3   80
10 100-3-10        3

3.6*1.3*2.4

7.5*2.3*4.2

 2.2   40
11 100-4-10       4

4.6*1.3*1.9

8.5*2.3*3.7

 3 4KW  56
12 100-5-10       5

4.6*1.3*2.3

8.5*2.3*4.2

 4   90
13 100-6-10 6

4.6*1.3*2.65

 8.5*2.3*4.5

 4   100
14 120-4-7 4

3.6*1.4*1.7

 7.5*2.4*3.5

 2.2   50
15 120-5-7 5

3.6*1.4*2.1

7.5*2.4*3.9

 3   70
16 120-6-7 6

3.6*1.4*2.4

7.5*2.4*4.2

 3   80
17 120-3-10
18 120-4-10 5

4.6*1.4*1.9

8.5*2.4*3.7

 3 4KW
19 120-5-10 6

4.6*1.4*2.3

 8.5*2.4*4.2

 4
20 120-6-10 7

4.6*1.4*2.65

 8.5*2.4*4.5

 4









Peanut Sieving Machine is a kind of primary equipment which is used to sort different size peanut kernels, when peanut kernels are collected from farmer, the first section is to grade and select them into different grades according to the size, but the imperfect kernels and moldy peanut kernels have to be picked out by workers, Peanut Sieving Machine can act this job exactly, it saves manpower with large extent. Peanut Sieving Machine designed by us has a full set of included hopper, conveyor, Peanut Sieving Machine, supporting base, finished peanut collector etc. 3/4/5 layers available, include the sieve residue, it can select 4-5 grades peanut together.
Peanut Sieving Machine has advantage of high efficiency, easy operation, and low maintenance, etc. It's an ideal choice for peanut farmers, householders and small cooperatives.
