The Most Popular Combine Harvester in 2014
Negotiable
MOQ: 3 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Grain, Wheat, Rape Seed.
Type:
Combine Harvester
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN CHONGQING SAHNGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Grain, Wheat, Rape Seed.
Type
Combine Harvester
Drive Type
Gear Drive
Usage
Grain Harvester
Place of Origin
Sichuan, China
Brand Name
K-BOS
Model Number
4LZ-4.0Z
Dimension(L*W*H)
5100*2600*2450
Weight
3000
Certificate
CE
Warranty
1 year
After-sales Service Provided
Overseas service center available
Specifications
Easy to operate,sensitiveSpecifications
Easy for operation and maintenance,
High harvest efficiency.
| Model: | 4LZ-4.0Z Combine Harvester | Application: | Grain, Wheat, Rape Seed. | |
| Type: | Full-feed, Track Combine | Safety & Handling: | See Operation Manual | |
| Make: | JinYang Bao | Occupation: | Manufacturer | |
| Description: | 4LZ-4.0Z combine with excellent performance in different crops and different field conditions, | |||
| the machine is easy for operation and maintenance, it is a safety and energy-saving machine. | ||||
| Featured with 37cc HST, 60 gearbox, wider rubber track, and bigger storing tank 1200L, bigger | ||||
| feeding capacity, and higher output. | ||||
| Quality System: | Production Plant Accredited to GB/T 19001-2008 / ISO9001 :2008. | |||
| Packing: | Strong standard export package suitable for long distance transportation. | |||
| Specification: | ||||
| Overall Dimension | Length×Width×Heights ( mm ): 5100×2600×2450 | |||
| Weight (kg) | 3000 | |||
| Feeding Capacity( kg/s ) | 4 | |||
| Harvesting Capacity(hm²/h): | 0.4-0.75 | |||
| Engine | Engine Model: 498BT/BZT/L; 4C6-88M22 | |||
| Rated Power ( kw/hp ): 65/88, 55/75 (Alternative) | ||||
| Engine Type: Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel. Turbocharged Engine. | ||||
| Rated Rotation Speed (r/min) : 2400 | ||||
| Fuel Tank Capacity ( l ): 70 | ||||
| Driving System | Crawlers(mm): 90×51×450 | |||
| Crawler Steering Radius ( mm ): left turn 2850; right turn 2850 | ||||
| Minimum Ground Clearance (mm): 280 | ||||
| Type of Gearbox: Hydraulic type + HST(3F, 3R) | ||||
| Theoretical Operating Speed ( km/h ): 2~4 | ||||
| Type of Brake: By Foot. | ||||
| Steering: Clutch and Brake. | ||||
| Cutting header | Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5 | |||
| Height Adjustment: Hydaulics. | ||||
| Cutting Bar Length ( mm ): 2228 | ||||
| Type of Cutting Bar Auger: Screw Conveying. | ||||
| Type of Blade: V Type / Left and Right. | ||||
| Rape Seed Extension: Optional | ||||
| Threshing & Separating | Threshing System: Spiked Tooth Axial Flow | |||
| & Cleaning System | Threshing Cylinder Size Diameter × Length ( mm ): 620×1700 | |||
| Reshresher: Blade Rotation. | ||||
| Vibrating Sieve: Adjustable Sieve+ Meshing Sieve | ||||
| Fan: Type: Swirl; Diameter( mm ): 405; Nos: 4 | ||||
| Grain Storing | Option 1: Grain Tank with Unloading Auger, Capacity ( l ): 1200 | |||
| Option 2: Manual Operation. | ||||
