Mobile Crane HONORSUN/HONORSUN 10t Truck Crane/ Camion Grue

Name: Mobile Crane HONORSUN/HONORSUN 10t Truck Crane/ Camion Grue
Brand: HONORSUN
SKU: 141307512
Availability: InStock

Qingzhou Honorsun Heavy Industry Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Rated Loading Capacity:

9640+500

Max. Lifting Load:

10 T

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Rated Loading Capacity 9640+500

Max. Lifting Load 10 T

Max. Lifting Height 26.5 M

Place of Origin Shandong, China

Brand Name HONORSUN

Model Number YGQY(OL)10H

Certification Ce certification

After-sales Service Provided Engineers available to service machinery overseas

Product model	YGQY(OL)10H
Chassis model	T-King
Total mass kg	9640+500
Overall dimension mm	895025003040
Rated elevating capacity kg	10000
Rated Lifting torque kN.m	240
Max. Lifting Height m	26.5
Main hook single load kg	1500
Main hook single elevating speed m/min	50
Auxiliary hook single load kg	500
Auxiliary hook single elevating speed m/min	100
Engine model	YANGCHAI 4102(YZ4DA7-30)
Derailleur model	MW5-38 With high and low speed auxiliary box
Tires	8.25-16 with spare tires
Braking form	Break air brake
Steering form	Hydraulic power steering
Crane jib structure	Category five hexagon box-type, hydrocylinder telescopic boom
Main Lifting Mechanism	Category two planet wheel with a brake inside
Auxiliary Lifting Mechanism	Category one gear brake motor
Swing Bearing	GB Φ1000 Tooth, material 50Mn intermediate frequency
Vertical hydraulicleg	Double-acting engineering oil cylinder
Horizontal hydraulicleg	Double-acting engineering oil cylinder
Platform	Anti-skidding and big
Protective Screening	Two-way
Night light	3 lamps control
Dynamic Motor	GB 11KW-4 pole
Crane Cab	Tailor-made
The central axially symmetrical	Four oil ways
Crane Start	Tailor-made
Throttle	Hydraulic
Warning Horn	Mono snail
Pressure gage and switch	Shockproof component
Power Takeoff	Driving indoor operation zip type
Hydraulic Oil Tank	Turntable rearmounted, counter weight combined type, special four-layer filters
