China Best River Sand Pump Dredger
1.Feature
Sand Pump Dredger
1.Sand pump dredger is widely used for dredging sand in river, lake and reservoir.
2.The company with gold sand production equipment, advanced technology, reasonable structure, reliable operation, easy maintenance. After years of production practice has proved that this production of alluvial gold vessels with a high degree of mechanization, large production capacity, less investment, and so on. Alluvial gold production is advanced mining joint equipment.
3.Simple hanging pump dredger structure, 8-inch water volume pumping sand sediment concentration can reach 20%, the amount of clay content of water with silt if the words can reach 20% -25%.
4.Product design, easy operation, high efficiency, suitable for river dredging, lake and reservoir dredging, land reclamation, port cleaning, Chousha so on. The equipment consists of the hull, conveyor systems, water systems, evacuation systems and other components, including the power delivery system, a clutch, mud pump, drain the system comprises a high pressure pump and vacuum devices.
2.Technical Parameters
Model | KDQSB50 | KDQSB75 | KDQSB75 | KDQSB100 | ||
Dimension (m) L*W*H | 5.0*4*1 | 5.0*4*1 | 5.5*4*1 | |||
Pontoons(m) 2sets | 5.0*1.0*1.0 | 5.0*1.25*1.0 | 5.5*1.25*1 | |||
Pump model | ZJQ60-30-15 | ZJQ75-25-15 | ZJQ75-35-22 | ZJQ100-18-11 | ZJQ100-35-30 | ZJQ100-45-37 |
Head(m) | 30 | 25 | 35 | 18 | 35 | 50 |
Discharge pipe diameter | 100MM | 100mm | 100mm | |||
Max.discharge distance | 400 | 180 | 300 | 110 | 300 | 450 |
Max. approved particles | 13 | 13 | 13 | 21 | ||
Cutter model | JD-1.5 | JD-1.5 | JD-1.5 | |||
Cutter quality | 2 | 2 | 2 | |||
Standard dredging depth(m) | 25 | 25 | 25 | |||
Min.clean water flows(standard dredging depth and Max.discharge distance) | 50 | 75 | 100 | |||
Max.standard dredging capacity m3/h | 10--15 | 15-22.5 | 20-30 | |||
| 5 | 5 | 5 | |||
Winch(electric) | 1.5kw 3sets | 1.5kw 3sets | 1.5kw 3sets | |||
steel wire diameter | 10mm | 10mm | 10mm | |||
positioning anchor | Four arrested anchor / 3 | Four arrested anchor / 3 | Four arrested anchor / 3 | |||
anchor weight | 40kg | 40kg | 40kg | |||
Ladder winch | 2.2kw,1set | 3kw,1set | 3kw,1set | |||
first layer pull | 1t | 1.5t | 1t | |||
steel wire diameter | 10mm | 12mm | 10mm | |||
Geneartor moel | HF-24GF | HF-24GF | HF-30GF | HF-24GF |
|
|
Main diesel engine model | K4100D5-1 | K4100D5-1 | K4102D3-1 |
|
|
|
Total power KW | 30KW | 30KW | 37.5KW |
|
| |
3.Detailed paragraph:
Working:
The pump:
1.Pre-sale services: Passion &thoughtful
We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
2.Sale services: Oversea Technicians
Oversea technicians will be sent to the jobsite for guiding the installation training operators and finishing the check and accept together with you.
3.After-sale services: Faithfulness
One year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
Qingzhou Keda Mining Machine Co., Ltd is a factory with professional manufacture experience, compared with trading company, we have more advantages as below:
1)competitive price
2)customers can visit our factory and test our machines at anytime.
3)repairing the machine in time.
4)on-time delivery
Our certification:
If our product is what you need,please contact without hesitate!
Contact person---Eden:
Eden Lee
Mobile:0086-536-2105419
Skype:kedamachinery04
Email:sales09 @miningmachine.net
