Small Automatic Gold Melter ElectroMelt Furnace
Main Features:
1. Large power, low frequency and good permeability;
2. High efficiency, low electricity consumption, easy operation and installation;
3. With full load design, it can work 24-hour continuously;
4. All solid IGBT frequency conversion and power adjustment, which can track frequency automatically;
5. Automatic protection functions such as over voltage, over current, overheating
assures safety and reliability of equipment.
6. Can melt 1-50 kg/time, need 2 to 20 minutes/time, the highest temperature can reach 1800 degrees.
Basic Parameter
| Model | 15A | 25A | 35AB | 45AB | 60AB | 80AB | 100AB | 120AB |
| Power | 2kw | 5kw | 10kw | 15kw | 20kw | 30kw | 45kw | 70kw |
| Working power supply | 220V | 380V | 380V | 380V | 380V | 380V | 380V | 380V |
| High frequency | 30~50KHZ | |||||||
| Intermediate frequency | 1~15KHZ | |||||||
| Weight | 15KG | 25KG | 35KG | 70KG | 70KG | 90KG | 120KG | 150KG |
| Amount of molten metal | 1~2kg | 1~4kg | 1~8kg | 1~15kg | 1~25kg | 1~40kg | 1~50kg | 1~100kg |
| Process time | ≤5min | ≤5min | ≤10min | ≤15min | ≤20min | ≤30min | ≤40min | ≤40min |
Water Pipe Connection Diagram
Qingzhou Keda ore machinery Co.,LTD. is a modern and formal ore machine manufacturer,which is professional at producing all kinds of mining equipment with ISO9001:2008. The gold wash plant has obtained PATENT both in utility and design. We are the ONLY manufacturer has this patent in China.
The company is established in 2002 primitively, covers an area of more about 20,000 square meters and equipped with modern type workshops and office . Nice product comes from excellent teamwork. Currently there are 120 stafves, including 2 senior engineers, 5 engineers, 15 technicians and 60 technical workers. Our company are more normative in management, our engineers are more professional in design and manufacture, our service are more comprehensive and thoughtful, and our price are more competitive with the best quality.
Successful cases
1.Rational and practical design according to customers' request proved.
2.Within warranty period,we provide free repair if quality problems emerge.
3.Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4.Free training of the first batch of operater proved, any question or problem about the products can be answered via online support,phone calls or on-sit support 24 hours.
If you have any question ahout our products or company, please let us know, we will try our best to make you satisfied.
