China Anchor Winch For Sale

US$ 10,000 - 30,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

KDJC

Qingzhou Keda Mining Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name KD

Model Number KDJC

Power Source Electric

Application Boat

Capacity 18mpa

Specifications

China Anchor Winch For Sale
1.Pressure:14Mpa-16MPa
2.Pull:2tons-15tons
3.discharge distance 1000m
4.ISO 9001

China Anchor Winch For Sale

I am so pleasure you can focus on the sand dredging winches of our company.

We are direct factory and can customize professional products according your requiement.

Our factory design the products to raise the quality,improve the efficiency,cut

down the cost as well as supporting teh production line.

Anchor Winch Production

Anchor Winch Feature:

1.Driven mode:elcetric or hydraulic drive

2.Clutch:Hydraulic operated

3.Control:local or remote control

4.Emergency:Quick release

5.Wire speed:to suit operational requirements

6.Brake:Manually operated band

7.Configuration:Single or double drum,linear or waterfall

Anchor Winch Basic Parameter:

Hydraulic Winch
Series	Model	First layer		Total Displacement (ml/r)	Difference of working pressures(Mpa)	Steel wire diameter (mm)	Drum Capacity (mm)	Weight(kg)
Series	Model	Pull Force(KN)	Rope Speed(m/min)	Total Displacement (ml/r)	Difference of working pressures(Mpa)	Steel wire diameter (mm)	Drum Capacity (mm)	Weight(kg)
KDJC3	KDJ3-30-65-15	30	0-35	2455	14.5	15	65	300
KDJC3	KDJ3-40-60-16	40	0-35	3267	14.5	16	60	300
KDJC4	KDJ4-50-87-20	50	0-40	4961	13.6	20	87	680
KDJC4	KDJ4-60-68-21.5	60	0-40	6138	14.2	21.5	68	680
KDJC5	KDJ5-80-100-24	80	0-40	9983	14.5	24	100	1200
KDJC5	KDJ5-100-90-28	100	0-40	12468	14.5	28	90	1200
KDJC6	KDJ6-120-170-30H	120	0-30	16714	17	30	170	2300
	KDJ6-150-153-34H	150	0-30	19041	18	34	153	2300
	KDJ6-180-140-38H	180	0-30	22852	18	38	140	2300
