Mini sand pumping barge
1.Keda Mini sand pumping barge Introduce
The dredger we produce non self-propelled,portable cutter suction dredger.
The hull uses dismantle and box-like structure, which equipped with horizontal
shifting devices, cutter ladder lifting devices, spud devices, deck crane and so on.
It can also be equipped with anchoring poles and trolley devices. Generally, it has
functions on dredging, conveying and discharging of mud or sand. It can produce
certain amount of vacuum by the centrifugal pump.
2. Mini sand pumping barge parameter
Basic CSD Parameter | ||||||
Model | KDTJ200 | KDTJ260 | KDTJ300 | KDTJ400 | KDTJ500 |
|
Dredger Body |
| |||||
Dimensions(L*W*H)m | 12.5*4.6*1.3 | 12.5*5.8*1.6 | 14.5*5.8*1.8 | 22*6.4*2 | 26*7.1*2.2 |
|
Engine room(m) | 7.5*2.25*1.4 | 8*2.8*1.6 | 9*3.2*1.8 | 12*3.4*2 | 14*3.5*2.2 |
|
Dredging data |
| |||||
Standard dredging depth | 6-7m | 6-8m | 8-10m | 12-14m | 12-14m |
|
Pump model | 8/6” | 10/8” | 12/10” | 14/12” | 450WN |
|
Water flow | 450m3/h | 800m3/h | 1100m3/h | 1900m3/h | 3200m3/h |
|
Suction pipeline diameter(mm/inch) | 260 | 300 | 350 | 400 | 500 |
|
Discharge pipeline diameter(mm/inch) | 200 | 260 | 300 | 400 | 500 |
|
Devices |
| |||||
Total power KW | 176kw | 258kw | 353kw | 640kw | 1200kw |
|
Generator set(kw) | 24 | 24 | 24 | 24 | 36 |
|
Cutter head |
| |||||
Diameter (mm) | 850-30 | 950-40 | 1100-50 | 1300-110 | 1700-140 |
|
Winch(hydraulic) |
| |||||
Ladder winches | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-12000 |
|
The parameter is just for your reference,we can design as your requirement.
3. Mini sand pumping barge components
4. Mini sand pumping barge shiping pictures
5. Mini sand pumping barge working site
6.Company Information
1)Qingzhou Keda Mining Machine Co., Ltd.mainly produces iron selecting equipment,
kinds of drederes, dredging equipment, sand washing and sand making equipment,
gold panning equipment, magnetic separating, crusher and so on,
2)Products can produce according to the customers requirement and geographical condition.
3)It is a modern large-scale mineral processing equipment manufacturer for research and development,engineering design, producing installation, commissioning and after sale service.
4)Honesty and credit is our bussiness value , customer first.First-class quality and first-class
service is the business life
7.FAQ
1.Where has your plant export to ?
Africa: Sudan,Ghana,Mali,etc.....
East South Asia :Burma,Philippines,Indonesia,etc...
LatinAmerica:Surinam,Chile
Others:Papua New Guinea
2.What's your main products ?
We focus alluvial gold mining equipment and cutter suction /chain bucket/jet suction dredger .Kindly contact us for catalog,please
3.What's your warranty ?
We have ISO cetification and provide 1year warranty for all of our products.All spare parts will be provided fast and cheap forever.
4.Do you also design plant ?
Yes.Although we have some popular models.but the real good palnt is designed for clients,based on the condition of gold mine site
Click here for more design details
5.How can I contact you ?
Alice Li
Kede Mining Machinery Co.,ltd
Tel:0086-536-3880600
Mobile:0086-13793603966
Email:sales06 @miningmachine.net
Skype:kedamachinery06
Add:Qingzhou City,Shandong Province,China.
