Specifications
WFS Rough Mixer/Grinder/Grinding Machine/ Herb MillHigh quality easy operation
WFS Rough Mixer/Grinder/Grinding Machine/ Herb Mill
Applications
The machine unit is the ideal machine for pharmaceutical, food and chemical industries. WFS could grind any material because of shear and impact theory, especially to the fibrous material.
Principle
Using fixed knife and rotating knife to cut and impact, finish grinding with rotating plate work. The product is separated from cyclone separator continuously and be discharged after filtered by bag filter.
Technical Parameter
|
Type
|
Power (kw)
|
Mesh
|
Capacity (kg/h)
|
Rotating speed of main axis (rpm)
|
Fineness of inlet raw material (mm)
|
Weight fineness
|
|
WFS130
|
2.2
|
20-200
|
-5-25
|
6000
|
10
|
|
|
WFS200
|
3
|
20-200
|
-20-90
|
4500
|
10
|
|
|
WFS250
|
5.5
|
20-200
|
-70-150
|
3000
|
10
|
|
|
WFS300
|
5.5
|
20-200
|
-100-200
|
2500
|
10
|
Chinese medicine crusher
|
