No.

Model

LMT5315TFCX

1

Chassis Model

SINOTRUK-CNHTC

1.2

Chassis Engine power KW /(r/min)

249/1900 KW /(r/min)

1.3

Chassis Emission Standards

Europe 4

1.4

Chassis Drive Type

8 × 4 Dual rear axle drive

1.5

Chassis Maximum speed (Km/h)

1.6

Chassis Full quality (Kg)

31000

1.7

Curb Weight (Kg)

17450

1.8

Chassis Wheelbase (mm)

1800+3800+1350

1.9

Dimensions (mm)

11100x2450x3720

2

Auxiliary Engine

Cummins

2.2

Auxiliary Engine Drive Model

Full hydraulic drive

2.3

Auxiliary Engine Power      KW /(r/min)

97/2300

3

Capacity of Gravel tank (M3)

12

3.2

Gravel Supplement(kg/min)

1700

3.3

Grave Measurement Type

Adjust the feed door

4

Capacity of Emulsion Bitumen Tank (L)

4000

4.2

Emulsion Bitumen Measurement Type

Hall sensor                pump speed adjustment

4.3

Emulsified Bitumen Insulation Type

Chassis hot water

5

Capacity of Water Tank (L)

4000

5.2

Water supplement (L/min)

300

5.3

Water Measurement Type

Flow meter / pump speed regulator / valve adjustment

6

Capacity of Additives Tank (L)

230

6.1

Additives Measurement Type

Flow meter valve adjustment

7

Capacity of Cement Tank (M3)

0.5

7.1

Cement Supplement (kg/min)

60

7.2

Cement Measurement Type

Screw speed regulation

8

Mix System

Biaxial strong stirring

8.2

Mix System Ability(kg/min)

1800-2000

9

Paver Width (m)

2.5—4.2

9.2

Paving thickness(mm)

3-15

10

Working Speed (Km/h)

2.3—2.5

No.

Name

QTY

Supplier/Model

1

Truck chassis

1

SINOTRUK-CNHTC Model:ZZ1317N3867D1H

2

Auxiliary engines

1

Cummins                     4BTA3.9

3

Transfer case

1

Italy HANSATMP    AM216SAE2RBD10SAEB

4

Hydraulic pump

6

Italy HANSATMP

5

Cement , belt drive motor

2

U.S.A. EATON          TE0080AS260AABJ

6

Paver,asphalt pump motor

3

U.S.A. EATON

7

Mix motor

1

Taiwan MAXMA                 MAT250C

8

Hydraulically balanced valve

2

Switzerland Bucher        MTKAVD-M22

9

Hydraulic accessories

1

PARKER,EATON

10

Asphalt pump

1

TG

11

Asphalt flow meter 2"

1

Germany Burkert /8041+8025+S020

12

Water flow meter 1.5"

1

China Shanghai Hongyi

13

Additive flow meter 1/2"

1

China Shanghai Hongyi

14

Water pump

1

U.S.A ACE               FMC-200HYD-310

15

High pressure water pump

1

China Taiwan Shuangmao

16

Vibration motor

1

China Wolong                 MVE200DC -24

17

Control system

1

Germany Siemens

18

Mix tank

1

China MeTong

19

Paver

1

China MeTong
