Wet Wire Drawing Machine
US$ 12,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Wanyi
Model Number:
weter tank machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Tank Wire Drawing MachineUS$ 13,000 - 23,000MOQ: 1 Set -
Small Wire Drawing MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Water Tank Wire Drawing MachineUS$ 10,000 - 25,000MOQ: 1 Set
-
Turn Over Wet Drawing MachineUS$ 12,000 - 19,000MOQ: 1 Set
-
Small Wire Drawing MachineUS$ 12,000 - 30,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Wanyi
Model Number
weter tank machine
Condition
New
After-sales Service Provided
Overseas service center available
LT14/350 wet drawing machine
equipment:
(1) pay-off stand
(2) simple shell oxygen removal descaling equipment
(3) LT14/350 drawing machine
(4) Tensile rack device
(5) take-up machine
(6) complete electrical control cabinet
2, main technical parameters and points:
(1) max inlet strength: 450Mpa or less
(2) max inlet diameter: 3.0 mm
(3) minimum outlet 0.5 mm
(4) largest compression ratio: 92%
(5)drawing the highest speed 12m/s normal use: 10m/s
(6) water and water pressure: 3m3 /h,water pressure 0.2 Mpa or more
(7)air and pneumatic: 1.0 m3/h air pressure 0.6Mpa or more
(8)motor:drawing and take-up machine adopts 22KW frequency 50HZ ac frequency conversion motor
