Trunk type take-up machine
1), application
this machine is used for receive copper wire,iron wire and a variety of wires can be used in devices such as wire drawing machine of water tank, increasing production and the lifespan of machine greatly, reducing the operator`s working intensity. This machine can match Y motor adopting frequency control. The receive wire speed of it can coordinate with the speed of wire drawing machine fully. This machine has reasonable structure, convenient operation and stable operation, also is an ideal device used in metal products industry, nonferrous metal and cable industry.
2), main technical parameters
1,take-up block 560
2,take-up material iron wire b≤80kgt/mm2
3,take-up diameter φ5.5—φ0.8 mm
4,take-up speed 250m/min
5,suitable motor power 11KW-6
6,operations center elevation 1600mm
7,unloading line weight max 1200kg
8,dimensions(length*width*height) 2250*1500*2160 mm
9,total weight about 2000kg
Main technical parameter:
Model |
XBSJ-750 |
XBSJ-650 |
XBSJ-400 |
Drum diameter |
Φ750mm |
Φ650mm |
Φ400mm |
Wire diameter of finished product |
Φ2.2-5.5mm |
Φ1.6-4.0mm |
Φ0.8-1.6mm |
Take-up speed |
300-600m/min |
300-640m/min |
400-800m/min |
Remarks |
The mechanical speed ratio and the diameter of drum all can be designed according to customers' needs. |
||
