Features of the equipment
1. turn-key for wire drawing machine line.
2. Easy operation and reliable control enables safe production and conveninent maintenance.
3. Application of 3-phase AC variable-frequency speed adjustment realizes smooth stepless speed regulation and saves more than 30% electric power.
Specification:
Items | Unit | Type |
Diameter of Capstan | mm | Φ550-Φ1400 |
Max diameter of inlet wire | mm | Φ16mm |
Intensity of material | M pa | ≤1200 |
Compression rate | % | 15-30 |
Wire drawing line | m/s | 6m/s-15m/s |
Single motor power | Kw | 11-75 |
About us
1.We are one of the leading wire drawing machine manufacturers with more than 18 years experiences with a high reputation.
2.We have gotten ISO9001:2008 standard and certificate.
3.Company location: Zhangjiagang City, 125km away from Shanghai,50Km away from Wuxi . Welcome to visit us, we will pick you up from Shanghai or Wuxi City
4.Number of employees: 100-200
5.We have a professional technical team, a good after-sale service team, an excellent production management team.we have ONE YEAR FREELY after-sale service.
6.We can design and produce various wire drawing machine line, auxiliary equipment according to customers’ special requirements
Successful experience / Markets
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria and so on.
| Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
| Reel diameter | mm | 900 | 800 | 700 | 560 | 400 |
| Draw passage | time | 9-12 | 10 | 9 | 10 | 10 |
| Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 |
| Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 |
| Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 |
| Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
| Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 |
| Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-20.02 | 18.61-16.74 |
| Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
