Mild Wire Drawing Machine
US$ 30,000 - 56,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
2.2mm
Outlet Diameter:
2.8mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Bull Block Wire Drawing MachineUS$ 30,000 - 80,000MOQ: 1 Set -
E71T-1 Flux Cored Solder Wire Drawing MachineUS$ 40,000 - 80,000MOQ: 1 Set
-
Vertical Wire Drawing MachineUS$ 30,000 - 60,000MOQ: 1 Set
-
Top Wire Drawing MachineUS$ 30,000 - 70,000MOQ: 1 Set
-
High Speed PLC Control Wire Drawing MachineUS$ 20,000 - 60,000MOQ: 1 Set
Condition
New
Inlet Diameter
2.2mm
Outlet Diameter
2.8mm
Brand Name
WANYI
Model Number
LZ
Voltage
380v
Power(W)
77kw
Dimension(L*W*H)
9X1.6X1.5M
Weight
8500KG
Certification
CE or SGS or your need
Warranty
one year freely
After-sales Service Provided
Engineers available to service machinery overseas
Max. entering (steel) wire strength:≥1000MPa
(2)Max. entering (steel) wire dia.:2.8-2.2mm
(3)Min. exiting (steel) wire dia.:1.0-0.8mm
(4)Pulling steel wire material:low carbon steel wire,
(5)Max. steel wire drawing speed:10-14m/s ( Normal using speed: 10m/s)
(6)Water volume :8m3/h (Water pressure ≥0.25MPa)
(7)Air volume:3.5m3/h (Air pressure ≥0.6MPa)
(8)Motors:drawing unit: 11KW AC freq. con. motor
Take-Up unit: 11KW AC freq. con. motor
(9)Drum of drawing machine:400mm
material:steel ZG45~55, hardness alloy tungsten carbide is spraying-painted on working surface, with HRC60, roughness ≤1.6Ra.
Drum using life: 10000hours if broken,we change freely
