Rotating Die Wire Drawing Machine

Zhangjiagang City Wanyi Machine Factory
Rotating Die Wire Drawing Machine thumbnail-1
Rotating Die Wire Drawing Machine thumbnail-2
Rotating Die Wire Drawing Machine thumbnail-3
Rotating Die Wire Drawing Machine photo-1
Rotating Die Wire Drawing Machine photo-2
Rotating Die Wire Drawing Machine photo-3
US$ 30,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
6.5 or 6.0 or 5.5mm
Outlet Diameter:
1.0 or 1.2mm
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Inlet Diameter 6.5 or 6.0 or 5.5mm
Outlet Diameter 1.0 or 1.2mm
Place of Origin Jiangsu, China
Brand Name wanyi
Model Number LZ400 straight line
Voltage 220/380V
Power(W) 7x11+7.5X1KW
Dimension(L*W*H) 8X1.4X1.5M
Weight 7500KG
Certification CE or SGS
Warranty one year freely
After-sales Service Provided Overseas service center available

rotating die wire drawing machinerotating die wire drawing machinerotating die wire drawing machine1.Equipment constituter: (1) rotating pay-off rack

                    (2)LZ7/400 straight line drawing machine

                    (3)tensile rack

                     (4) SG400 (or 300)take up machine

                     (5) human machine interface display screen

                     (6) Whole set of electrical appliance control cabinet

2. Work areas:   (1) input diameter: 2.0 --2.8mm

              (2)input strength:  500Mpa

              (3) input material: low-carbon wire

              (4) output diameter: 0.8-1.1mm

3. Drawing speed: (1) max: 18m/s  (2) average: 15m/s with output 1.1mm 2.4t/d (8h per day)    0.9mm1.7t/d (8h per day)

4. Water- air pressure: (1) hydraulic pressure >0.2Mpa

                   (2) barometric pressure>0.5Mpa

5. Electric motor standard: (1)drawing machine: 11KW     AC motor

                    (2) wire coiling machine: 7.5KW  AC motor

6. Reel form: (1) diameter: 400mm

           (2) Material: ZG45 steel, surface spray finishing with carbonized tungsten alloy powder, hardness more than HRC60, surface roughness concentration less than 1.6Ra

           (3) Service life: 10000h
