Sr. |
Name |
Unit |
Data |
1 |
Drawing machine name |
|
LZ13/600 |
2 |
Drawing machine and pull mode |
|
Straight line tuning type |
3 |
Draft number |
|
13 |
4 |
Coil diameter |
mm |
Φ600 |
5 |
Speed adjustable mode |
|
AC freq. Con. Speed Adjustable |
6 |
Motor power |
KW |
8X37+5×30+1X22 |
7 |
Wire-in diameter |
mm |
Max Φ7.0 |
8 |
End product diameter |
mm |
Min Φ1.5 |
9 |
Average compression |
% |
≤21.1% |
10 |
Design drawing speed |
m/s |
max16(light load high speed, heavy load low speed) |
11 |
Control mode |
|
Fully digital |
12 |
Logical control |
|
PLC |
13 |
Wire-in strength |
MPa |
≤1250 |
14 |
Carbon content in material |
|
high and low carbon steel wire |
15 |
Drum cooling |
|
Self contaminant release narrow seam type water cooling + outer ring type fan cooling. |
16 |
Die box |
|
Direct water cooling |
17 |
Cooling water pressure |
|
0.2~0.3Mpa |
18 |
Pneumatic system |
|
Air pressure≥0.5Mpa |
19 |
Stop time |
S |
Normal stop≤50s,EMG stop≤5s |
20 |
Pay-off mode |
|
Duck bill type pay-off machine |
21 |
Take-in mode |
|
I-type take-in coil |
22 |
Total length of production line |
M |
About 30M |
Model |
No of drafts |
Max.inlet wire(mm) |
Min.outlet wire(mm) |
Motor power (KW) |
Production speed(M/S) |
LZ300 |
8-12 |
2.5 |
0.4 |
3-4.5 |
25 |
LZ350 |
8-12 |
3.5 |
0.6 |
5.5-11 |
25 |
LZ400 |
8-12 |
4.2 |
0.75 |
7.5-15 |
25 |
LZ450 |
8-12 |
4.5 |
0.96 |
15-22 |
218 |
LZ600 |
6-8 |
6.5 |
1.4 |
22-37 |
16 |
