Spring Wire Drawing Machine

Spring Wire Drawing Machine thumbnail-1
Spring Wire Drawing Machine thumbnail-2
Spring Wire Drawing Machine thumbnail-3
Spring Wire Drawing Machine thumbnail-4
Spring Wire Drawing Machine thumbnail-5
Spring Wire Drawing Machine thumbnail-6
Spring Wire Drawing Machine photo-1
Spring Wire Drawing Machine photo-2
Spring Wire Drawing Machine photo-3
Spring Wire Drawing Machine photo-4
Spring Wire Drawing Machine photo-5
Spring Wire Drawing Machine photo-6
US$ 25,000 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wire Drawing Machine
Use:
Wire
Contact Supplier Request Quote Chat Now
Zhangjiagang City Wanyi Machine Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or as u nned
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wire Drawing Machine
Use Wire
Place of Origin Jiangsu, China
Brand Name wanyi
Model Number LZ
Voltage 380V
Power(W) 30X1+22X7KW
Dimension(L*W*H) 8.5X1.5X1.5
Weight 9000kg
Certification third part (SGS CE) or else
Warranty ONE YEAR
After-sales Service Provided Engineers available to service machinery overseas



spring wire drawing machinespring wire drawing machinespring wire drawing machineLZ8/600  stainless steel wire drawing machine:

No.

Name

Data

1

Drawing type

LZ8/600

2

Drawing passes

1-8

3

Inlet wire diameter

MaxΦ6.5mm

4

End product diameter

 Min Φ2.0mm

5

Average compression

22.7%

6

Drawing speed

Max 7m/s;

7

Logical control

PLC

8

Inlet Wire strength

≤700 MPa

9

Drawing material

stainless steel wire, etc. 304 314

10

Block

(1). diameter:Φ600mm

(2). material: 45 steel, the surface of drum is coated by tungsten carbide; hardness: HRC58-62 ; roughness: ≤1.6Ra.



11

Motor Power

30KW

11

Die box

Direct water cooling; lubrication bath and water cooling bath:

12

Cooling water pressure

0.2~0.3Mpa

13

Pneumatic system

Air pressure≥0.5Mpa

14

Control system

(1). Converter; Schneider

(2). PLC; Siemens

(3).Low voltage elements: Schneider

(4).Touch screen: Siemens

14

Stop time

Normal stop≤10s,EMG stop≤5s
