Steel Wire Drawing Machine

Steel Wire Drawing Machine thumbnail-1
Steel Wire Drawing Machine thumbnail-2
Steel Wire Drawing Machine photo-1
Steel Wire Drawing Machine photo-2
US$ 50,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
1.5-10mm
Outlet Diameter:
0.05~8.0mm
Contact Supplier Request Quote Chat Now
Zhangjiagang City Wanyi Machine Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
your needs
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Inlet Diameter 1.5-10mm
Outlet Diameter 0.05~8.0mm
Place of Origin Jiangsu, China
Brand Name WANYI
Model Number LZ300/350/400/450/500/560/600/700/800/900/1200
Voltage 380V/220V
Power(W) 7.5~160KW
Dimension(L*W*H) 7000*1600*1500
Weight 1.5~40Ton
Certification CE/CB//CQC/ISO9001
Warranty One Year Warrantly
After-sales Service Provided Engineers available to service machinery overseas

Sr.

Name

Unit

Data

1

Drawing machine name



            LZ13/600

2

Drawing machine and pull mode



Straight line tuning type

3

Draft number



13

4

Coil diameter

mm

                Φ600

5

Speed adjustable mode



AC freq. Con. Speed Adjustable

6

Motor power

KW

8X37+5×30+1X22

7

Wire-in diameter

mm

Max               Φ7.0

8

End product diameter

mm

Min                Φ1.5

9

Average compression

%

≤21.1%

10

Design drawing speed

m/s

max16(light load high speed, heavy load low speed)

11

Control mode



Fully digital

12

Logical control



PLC

13

Wire-in strength

MPa

≤1250

14

Carbon content in material



high and low carbon steel wire

15

Drum cooling



Self contaminant release narrow seam type water cooling + outer ring type fan cooling.

16

Die box



Direct water cooling

17

Cooling water pressure



0.2~0.3Mpa

18

Pneumatic system



Air pressure≥0.5Mpa

19

Stop time

S

Normal stop≤50s,EMG stop≤5s

20

Pay-off mode



 Duck bill type pay-off machine

21

Take-in mode



I-type take-in coil

22

Total length of production line

M

About 30M



Model

No of drafts

Max.inlet wire(mm)

Min.outlet wire(mm)

Motor power

(KW)

Production speed(M/S)

LZ300

8-12

2.5

0.4

3-4.5

25

LZ350

8-12

3.5

0.6

5.5-11

25

LZ400

8-12

4.2

0.75

7.5-15

25

LZ450

8-12

4.5

0.96

15-22

218

LZ600

6-8

6.5

1.4

22-37

16
