Hose Wire Drawing Machine
US$ 55,000 - 85,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LZ8/400
Voltage
380/220V
Power(W)
11X8KW
Dimension(L*W*H)
7.5X1.4X1.5M
Weight
6500kg
Certification
third parts
Warranty
one year freely
After-sales Service Provided
Overseas service center available
Specification:
Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
Capstan diameter | mm | 1200-900 | 800 | 700 | 560(600) | 400(450) |
Drawing dies | time | 9-12 | 10 | 9 | 10 | 10 |
Max inlet diameter | mm | φ14-8 | φ10-8 | φ8-6.5 | φ6.5-5.5 | φ3.5-2.5 |
Min outlet diameter | mm | φ5-3 | φ4-2.5 | φ3-2.5 | φ2-1.8 | φ1.1-0.8 |
Drawing speed | m/min | 300 | 360 | 480 | 720 | 840 |
Tensile strength | Mpa(max) | 1300 | 1300 | 1300 | 1300 | 1300 |
Total compression rate | % | 87.24-92.89 | 90.53-90.23 | 85.94-85.21 | 90.53-89.29 | 90.12 |
Average compression rate | % | 20.45-19.58 | 21.00-20.75 | 19.58-19.13 | 21.00-20.02 | 20.50 |
Motor Power | Kw | 110-90 | 90-55 | 75-55 | 37-22 |
|
